1. Overview
In the intelligent energy-saving lighting controller sensing and control system of L5504RVF, L5506RVF, and L5512RVFP, each device is relatively independent. The failure of a single device in the system will not cause the entire control system to paralyze. Zhejiang Juchuan Electrical Technology Co., Ltd. Tel: 0577 - 27877837, Quotation QQ: 421563834. The control signal (low voltage) is separated from the load circuit (high voltage). The devices are connected by 2 pairs of twisted low-voltage cables to form a bus network. The system features distributed intelligent control and openness, and can be seamlessly connected with building automation systems, security and fire protection systems, outdoor lighting systems, and stage lighting control systems.
System Control Mode
Infrared control
The infrared remote control device can increase the flexibility and convenience of control. It can easily integrate the E-BUS system with other systems, such as TVs, power amplifiers, DVDs, and air conditioners.
Wireless remote control
The wireless remote control uses RF radio frequency technology, and the control range is not limited by space, making the control more flexible.
Scene control
Multiple scenes can be selected with time attributes, and the brightness can be fine-tuned. It is suitable for applications that require multi-position control, such as classrooms, audio-visual control, reception desks, and security control centers.
Centralized touch screen control
The system supports touch screens on different platforms, such as iPad, Android, WinCE, and Windows. Through the touch screen, all devices in the system can be controlled, including lights, curtains, air conditioners, background music, security systems, and home theaters.
Centralized central control
The system has multiple interfaces to interact with the central control system, such as RS232, RS485, Bacnet, ModBus, UDP/TCP, and OPC. Through relevant interfaces and protocols, the central control system can monitor and control the DL-BUS system.
3. Main technical parameters
Input voltage: DC24V
Bus power consumption: 30mA/DC24V
Number of buttons: 2, 4, 6, 8, 12
Environmental conditions:
Operating temperature: 0℃~45℃
Operating relative humidity: 20%~90%
Storage temperature: -40℃~+55℃
Storage relative humidity: 10%~93
Connection system
No gateway or server host is required. No technical guidance is needed for installation, and networking is very simple.
The computer does not need high configuration. It supports the 32-bit WIN 7 system and the Android system on mobile phones.
For the intelligent lighting control module Y-BUS system, no signal amplifier is required within a wired communication distance of 5 kilometers.
Intelligent lighting control module for building electrical control operations:
The terminal of the building intelligent lighting monitoring system is used by the monitoring room to operate and monitor the lighting part of the building. Managers only need to operate the entire building's circuits in the monitoring room without having to personally go to the site for inspection and on - site operation. They can operate and check whether the lights are on/off just at the monitoring terminal.
Installation methods of the L5504RVF, L5506RVF, L5512RVFP intelligent energy - saving lighting controller sensing and control system:
1. Install on the rail. The 4 - channel intelligent lighting module is equivalent to a 4 - position switch, the 6 - channel intelligent control module is equivalent to a 6 - position switch, and the 8 - position intelligent lighting control module is equivalent to an 8 - position switch.
2. The module wiring is very convenient with direct input and output.
3. Only one bus line is needed, reducing wiring errors.
4. The wiring terminals are large enough to pass 25 - square wires.
Wiring demonstration:
1. The switch is a Chint switch. A 16A switch is directly connected to the module input terminal, and the input terminal is directly connected to the lamp.
2. The bus, modules are directly connected in series and then connected to the computer.
