Why CCD Detection Equipment is Very Important in the Production of Lithium Battery Packs

In the production of lithium battery packs, CCD detection equipment plays a crucial role for the following reasons:

Firstly, it can accurately detect various defects and abnormalities on the surface of lithium battery cells, such as scratches, dents, and foreign matter. This helps to ensure the quality and integrity of the battery cells and reduces the risk of potential safety hazards.

Secondly, CCD detection equipment can precisely measure the dimensions and geometries of the battery cells, ensuring that they meet the required specifications. This is essential for the proper assembly and performance of the lithium battery pack.

Moreover, it can monitor the consistency and uniformity of the battery cells, helping to identify any inconsistent or substandard cells that might affect the overall performance and lifespan of the battery pack.

It also enables real-time detection and feedback, allowing for immediate adjustments and improvements in the production process to maintain high quality standards.

Furthermore, with the increasing demand for high-quality and reliable lithium battery packs in various industries, CCD detection equipment provides an effective means to ensure the quality and reliability of the final products, enhancing the competitiveness of the manufacturers.

In summary, CCD detection equipment is of great significance in the production of lithium battery packs, as it helps to guarantee the quality, performance, and safety of the batteries, and promotes the development and application of the lithium battery industry.

TOP Battery machine factory contact number

Shenzhen AITOP Intelligent Equipment Co., Ltd.

Email :sales(@)

wehcat/whatsapp /Phone :008618098919495/008618435204981/18098989643

+8618820281861

CCD Tester Battery Cell Positive and Negative Tester & Battery Pack Welding Testing Equipment

1. Function description

CCD solder joint detector is an automatic equipment for lithium battery processing, which has the functions of automatic positive and negative pole detection, positive and negative solder joint detection, solder joint defect differentiation, automatic discharge, etc.

2. Process flow

Feeding and positioning of electric core → positive and negative pole detection → positive and negative solder joint detection (CCD) → NG automatic sorting → OK automatic discharging

3. Mechanical structure

1) Feed positioning of battery core

2) Polar ear leveling

3) CCD solder joint detector has high resolution image acquisition, artificial intelligence image processing and recognition technology to improve defect recognition rate

4) CCD welding detector has the advantages of fast recognition speed and high accuracy. It can select anti-static belt without damaging the battery

5) Humanized programming, easy to learn and understand.

CCD Testing Machine

Item: CCD testing machine

Model No.: TOP-CCD

Battery Types: 18650/21700/26650/32650/32700/32140/33140

Warranty: 1 year

MOQ: 1 set

Battery CCD Testing Machine Vision Inspection Equipment

Products Description

CCD vision inspection equipment refers to the machine vision products CCD image sensor will be taken in the target into an image signal, transmitted to the special image processing system, according to the pixel distribution and brightness, color and other information, into a digital signal; image system to these signals for a variety of operations to extract the characteristics of the target, and then according to the results of the discrimination to control the field of equipment action of a kind of inspection equipment.

Configuration Parameter

1. Equipment Power: 600W, 220V AC input, 50Hz.

2. BATTERY  Range: cylindrical core 14430/14500/18500/18650/21700/26650/32650, etc.

3. Suitable Detection Range: 400 * 300 mm, if more customized

4. After sample collection, 360-degree rotation position can be detected

5. Parameters set, one-click start detection mode

6. Simple function setting, easy to understand and operate, no need for on-site training

7. The Industrial Control Computer supports the function of sudden power failure, and the database works normally

8. Local database, mainly for cylindrical cell positive and negative electrode data, other categories are not compatible

9. DETECTION SPEED: 100PCS/1.5 S

10. TESTING ACCURACY: the cell is not deformed or rusty, 100%

11. Mass storage product parameters, call out parameters direct detection

12. Equipment Dimensions: L900 * W720 * H1600mm

13. Weight of equipment: 80 kg

 inspection machine, ccd tester

Hot Tags: ccd testing machine, China ccd testing machine manufacturers, suppliers, ccd testing machine, ccd visual

4. Specifications

5.  Equipment configuration list

● touch screen: Wellington

● PLC: motion controller

● step motor: Bifu

● servo motor: Mitsubishi & lechuang

Sensors: Panasonic and OMRON

● bearing: Japan NSK

● cylinder: Adec

● switching power supply: Mingwei, Taiwan

Product description:

The lithium-ion battery pack welding quality inspection machine is used to detect fake welding and missing welding of battery packs, and provides guarantee for the quality of battery pack welding.

Scope of application:

This battery pack welding quality inspection machine is suitable for the rapid inspection of the welding reliability of lithium-ion battery packs of ultrasonic welding equipment &  wire bonding machine, including 18650 battery module and 21700 battery module.

Brief introduction of the battery pack inspection equipment
