Multi-functional , high duty cycle
TIG-200/250A mosfet
TIG-315/400ST IGBT TUBE
TIG-400/500 IGBT MODULE
TIG/MMA two function
Inverter IGBT technology
Over heat/over current protection
HF ARC
Intelligent air cooling
Model |
TIG-200 |
TIG-250A |
TIG-315 |
TIG-400ST |
TIG-400 |
TIG-500 |
Rated input voltage(V) |
1p 220V±15% |
1p 220V±15% |
3p 380V±15% |
1p 220v/380V±15% |
3P 380v±15% |
3P 380v±15% |
Input Frequency(HZ) |
50/60 |
50/60 |
50/60 |
50/60 |
50/60 |
|
Rated input capacity （KVA） |
4.5 |
6.3 |
11.3 |
13.8 |
13.8 |
15.8 |
Duty cycle(%) |
45 |
45 |
60 |
45 |
60 |
60 |
No-load voltage(V) |
56 |
56 |
76 |
76 |
76 |
76 |
Current range (A) |
20-160 |
20-185 |
15-255 |
20-280 |
20-370 |
30-430 |
Efficiency (%) |
85 |
85 |
80 |
85 |
80 |
80 |
Power factor |
0.90 |
0.90 |
0.90 |
0.90 |
0.90 |
0.90 |
Plate thickness (mm) |
0.3-2.5 |
0.3-5 |
0.5-8 |
0.5-8 |
0.5-12 |
0.5-16 |
Weight 9KG) |
6.8 |
8.5 |
10.3 |
16.8 |
19.3 |
21.3 |
Dimension (mm) |
368*152*315 |
368*152*315 |
420*205*350 |
490*240*420 |
500*270*445 |
500*270*445 |
