10Gbps SFP+ 1310nm Transceiver, 20km Reach

This 1310nm DFB 10Gigabit SFP+ transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 10km/20km.

Features:

  • Optical interface compliant to IEEE 802.3ae 10GBASE-LR

  • Electrical interface compliant to SFF-8431

  • Hot Pluggable
    1310nm DFB transmitter, PIN photo-detector                                                                                                                                       Operating case temperature: 0 to 70 °C

  • Low power consumption

  • Applicable for 10km/20km SMF connection

  • All-metal housing for superior EMI performance

  • Advanced firmware allow customer system encryption information to be stored in transceiver

  • Cost effective SFP+ solution, enables higher port densities and greater bandwidth

Applications:

  • 10GBASE-LW at 9.953Gbps

  • 10GBASE-LR at 10.3125Gbps

  • Other optical links

Table 1 - Absolute Maximum Ratings

ParameterSymbolMin.Max.Unit
Supply VoltageVcc-0.54.5V
Storage TemperatureTs-40+85°C
Operating Case TemperatureTop0+70°C
Operating Humidity---5+85%
RX Input Average PowerPmax---0dBm


 Table 2 - Recommended Operating Conditions


ParameterSymbolMin.Typ.Max.Unit
Power Supply VoltageVcc3.1353.3003.465V
Operating Case TemperatureTop025+70°C
