25Gb/s SFP28 1310nm 10km Fiber Channel
Transceiver Module

Features:

  • Up to 25.78Gb/s data links

  • 1310nm DFB laser and PIN receiver

  • Up to 10km on 9/125um SMF

  • Hot-pluggable SFP footprint

  • Digital diagnostic capabilities

  • Class 1 laser safety certified

  • Cost effective SFP28 solution, enables higher port

  • densities and greater bandwidth

  • RoHS-10 compliant and lead-free

  • Single +3.3V power supply

  • 2-wire interface for management specifications

  • compliant with SFF-8472 digital diagnostic

  • monitoring interface for optical transceivers

  • All-metal housing for superior EMI performance

  • Case operating temperature

  • Commercial: 0 ~ +70ºC

  • Extended: -10 ~ +80ºC

  • Industrial: -40 ~ +85ºC

Applications:

  • High-speed storage area networks

  • Computer cluster cross-connect

  • Custom high-speed data pipes

  • Inter Rack Connection

Table 1 - Absolute Maximum Ratings

ParameterSymbolMin.Max.Unit
Storage TemperatureTs-4085ºC
Power Supply VoltageVcc-0.53.6V
Relative Humidity
(non-condensation)		RH595%
Damage ThresholdTHd3---dBm
Operating Case TemperatureTop070ºC
-1080
-4085


 Table 2 - Recommended Operating Conditions


ParameterSymbolMin.Typ.Max.UnitNotes
Power Supply VoltageVcc3.1353.33.465V
Date Rate------25.78---Gb/s
Control Input Voltage High---2---VccV
Control Input Voltage Low---0---0.8V
Link Distance (SMF)D------10km9/125um

Product Tags: 25G Optical Module , SFP28 Transceiver , CWDM Transceiver Module
