CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE

CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE thumbnail-3

CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE thumbnail-4

CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE thumbnail-5

CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE photo-1

CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE photo-2

CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE photo-3

CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE photo-4

CW6280B Conventional Horizontal Heavy Gap Lathe Machine With CE photo-5

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Business Type:

Manufacturer

Year Established:

2018

Factory Size:

Below 1,000 square meters

Contact Supplier Request Quote Chat Now

Jingjiang Fuji Technology Co., Ltd.

4Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Description

The heavy horizontal lathe machine is especially designed for big workpiece cutting;

All gears hardened with precision guideway;

	UNIT	CW6180B(without gap) CW6280B(with gap)
Swing in gap	mm	1100
Swing over cross slide	mm	800
Distance between centers	mm	4000
Spindle bore	mm	130
Spindle speeds	rpm/steps	10-800/18
Cross slide travel	mm	480
Top rest travel	mm	225
Rapid travel	mm/min	Longitudinal Axe Z: 3200
Rapid travel	mm/min		Longitudinal Axe X: 1900
Quill diameter	mm	90
Quill travel	mm	260
Quill taper		MT5
Bed width	mm	550
Metric threads	mm/kinds	1-240/53
Inch threads	tpi/kinds	30-2/31
Module threads	mm/kinds	0.25-60/46
Diametrical pitch threads	tpi/kinds	60-0.5/47
Main motor power	kw	15

Detailed Images

Packing&Shipping

The machine will be fastened on the container with steel ropes

Put anti-rust grease on the bed wad to protect the machine.

The plastic bag is covered on the lathe to protect dust or moisture.

Company Introduction

Located in Anhui Chizhou High-tech Development Zone, Chizhou WMT Group operates two companies. One is Chizhou WMT CNC Machinery Co. Ltd and the other is Chizhou WMT CNC Industrial Co., Ltd. The group deals in CNC machine, milling and drilling machine, drilling machine, lathe machine and all kinds of multi purpose machines. Focusing on the aim of Service Oriented and Quality formost, many products are originally designed, carefully produced and favourably promoted. It is worth mentioning that the group has successfully sold various machines to more than 50 countries and regions all over the world. The group as well as the machines enjoys wide and well-known popularity in European and American market. Dedicated to the policy of precision and promotion from stability, the group spares no effort in innovation, improvement, integrity management and insured quality.
