Parallel Lathe Metal Cnc Lathe CK6132X500 Good Rigid Lathe Machine Cnc With CE
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Parallel Lathe Mini Lathe Machine Cnc CNC210 Benchtop Cnc Lathe Machine
-
Lathe Machine STL420 China CNC Slant Turning Lathe Machine for Metal
-
Lathe Machine CK5116 Single Column CNC Vertical Lathe Machine for Heavy Cutting
-
Parallel Lathe CK6150 X750 Length Torno CNC for Threads Making
-
Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE
-
Wmtcnc Mini Cnc Lathe Machine Metal YCK-6150L Lathe Machine for Metal
Product Description
Products Description
CNC lathe CK6132 Features:
1. High rigidity casting bed.
2. High precision spindle bearing.
3. Bed guideways industively hardened.
Specification | CK6132x500/750/1000mm |
Max.swing over bed | Φ320 mm |
Max.swing over carriage | Φ150 mm |
Distance between centers | 500/750/1000mm |
Spindle bore | 40mm |
Spindle nose | A2-5 |
Rail width | 212mm |
Taper of spindle bore | MT5 |
Chuck | 6'' |
Range of speed (Variable) | 150-2500 rpm |
X axis travel | 180mm |
Z axis travel | 500/750/1000mm |
X/Z rapid speed | 4/7m/min |
X/Z screw | 2004/4006 |
Station of toolpost | 4 or 6 |
Max. section of tool | 20*20mm or 16*16mm |
Stroke of tailstock sleeve | 100mm |
Dia./hole of tailstock sleeve | 32mm/MT3 |
Main motor power | 2.2kw or 3.7kw |
Coolant pump power | 120w |
Overall dimenstion (L*W*H) | 1600/1920/2100x1120x1750mm |
Packing size (L*W*H) | 1815/2120/2300x1300x2000mm |
NW/GW | 800/900/1050kg;950/1050/1200kgs |
Detailed Images
Standard Accessories:
Cooling system
Auto-lubricating system
Work lamp
GSK-980TDc controller with feeding servo motor
4-Position electrical tool post
Manual 3-jaw chuck
Optional Accessories:
GSK218M controller
Simens 808D controller, Advance controller
Fanuc Oi TF controller
6-Position electrical tool post
Hydraulic chuck
Bar Auto-feeding (KT-16 and KT-20)
Gang tools type
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ? A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
Related Products
CNC Lathe CK6150
91.8% Response Rate
CNC milling machine VMC850L
91.8% Response Rate
Manual Lathe CS6266C
