Factory Sell SHL450/320 45-degree CNC Slant Bed Lathe Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Factory Direct Sell SWL550/1000 35-degree CNC Slant Bed Turning Center Lathe Machine From China
-
Efficient TX700 3-axis CNC Turning Center Lathe Machine With 12-station Power Turret for Metalworking
-
High Speed Spindle VK450 Vertical Type Cnc Lathe Machine With 8-station Turret
-
VK600 Vertical Type Cnc Lathe Machine With 8-station Turret
-
Dual Spindle SWL450S/650 35-degree CNC Turning Center Slant Bed Lathe Machine From China
-
35 Degree Slant Bed TX500EY Cnc Lathe Turning Center
Product Description
Product Description
SHL450/320 45-degree CNC slant bed lathe machine
Main Features:
1. SHL lathes have a heavy-duty cast base with “true align” slant bed design.
2. The machine bed, headstock and turret are aligned on the same plane.
3. This design reduces heat built-up and resulting thermal expansion.
4. Additional resulting efficiencies from the “true align” design are greater rigidity and smoother operation which provides a variety of benefits.
5. You can expect to produce highly accurate parts with extremely fine surface finishes.
6. There are multiple benefits to having a lathe that combines such a large sized “vibration damping” solid, cast base.7. PLUS, properly aligned and balanced components.
8. The SHL450/320 CNC slant bed lathe features a mono-block bed/spindle design for increased rigidity and vibration damping. Even during heavy cutting operations.
9. The rigid foundation on the SHL450/320 also assures precision and repeatability during high speed turning operations.
10. Ture slant bed extremely minimizes the impact of thermal expansion to precision.
11. 45 degree slant bed is more convenient for scrap iron.
12. Better dynamics and higher precisions.
13. It realizes an optimized combination of high-precision, high bearing capacity, good running speed and it is more durable.
14. Increasing the versatility and automation of the lathe.
15. Better water-resistant and scrap-iron-resistant.
Some of these benefits include:
1. Smoother slide surface operation.
2. Higher speed and accuracy.
3. Fewer machine adjustments and lower maintenance costs.
4. Shortened machine warm-up time.
5. Lower power consumption.
Specification | Unit | SHL450/320 | ||
Capacity | Chuck size | inch | 8" | |
Max. swing dia. over bed | mm | Ø450 | ||
Max. length of workpiece | mm | 320 | ||
Max. swing dia. over slide | mm | Ø220 | ||
Spindle | Spindle bore | mm | Ø62 | |
Max. dia. of through-hole | mm | Ø52 | ||
Spindle nose | type | A2-6 | ||
Spindle speed | rpm | 4000 | ||
*2000 | ||||
Main motor power | kW | 7.5/11 | ||
Axis | X axis travel | mm | 250 | |
Z axis travel | mm | 320 | ||
X/Z rapid traverse | m/min | 20/20 | ||
Turret | No. of tool stations | nos | 8,*12 | |
Tool shank size | mm | 25X25,*20X20 | ||
Structure | Slant bed degree | 45 | ||
Guideway type | LM | |||
Others | Power capacity | kVA | 15 | |
Overall dimension (LxWxH) | mm | 2290X1600X1810 | ||
Weight (about) | kg | 3300 | ||
Detailed Images
Company Profile
Professional Service
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4: What’s the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes.we have professional engineers and designers. We can provide OEM services.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
A1: Warranty time is 13 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4: What’s the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes.we have professional engineers and designers. We can provide OEM services.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
