Cnc Lathe Machine CK32A3-S High Precision Cnc Lathe Swiss Type for Metal Turning and Milling in China
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cnc Lathe CK32A3 High Precision Cnc Lathe Swiss Type for Metal Turning and Milling in ChinaNegotiableMOQ: 1 -
High Precision QK1319 1500mm Big CNC Pipe Threading Lathe MachineNegotiableMOQ: 1
-
Factory Sell SHL450/320 45-degree CNC Slant Bed Lathe MachineNegotiableMOQ: 1
-
Factory Direct Sell SWL550/1000 35-degree CNC Slant Bed Turning Center Lathe Machine From ChinaNegotiableMOQ: 1
-
Efficient TX700 3-axis CNC Turning Center Lathe Machine With 12-station Power Turret for MetalworkingNegotiableMOQ: 1
Product Description
High precision CNC lathe CK32A3-S cnc lathe swiss type main features:
1. High rigidity casting bed;
2. High precision spindle bearing;
3. Bed guideways industively hardened.
1. High rigidity casting bed;
2. High precision spindle bearing;
3. Bed guideways industively hardened.
Specification | CK32A3-S |
Cutting speed | 1-4000mm/min |
X rapid travel speed | 20000mm/min |
Z rapid travel speed | 20000mm/min |
Spindle through diameter | Φ33mm |
Max. bar throught hole | Φ32mm |
Max. revolving dia. | Φ400mm |
Spindle center height from the ground | 1000mm |
Spindle speed | 0-4000r/min |
spindle motor power | 4kw |
X stroke | 600mm（Diameter value） |
Z stroke | 300mm |
Guideway | Linear guideway |
Machine size | 1600*1410*1930mm |
Optional Accessories | ||||
Y axis multi function power tools base | ||||
power tool | end face | 4 nos | ||
side face | 4 nos | |||
power | 2kw | |||
revolving speed | 3000r/min | |||
ER collet | ER16 | |||
tool post | 16*16 square tool shank+∮20 boring tool shank | 4 nos(+2 nos）+5 nos | ||
Machine Show
Detailed Images
Company Profile
Professional Service
Customers' Feedback
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
