Product Description
CK61200/6000 Heavy Duty CNC Lathe Introduction:
1. This series CNC lathe is universal standard extra heavy duty automatic machine equipment, for metal processing suitable to process extra big size shaft and plate workpiece. 2. With the main characters such as reliable structure, easy operating and high accuracy. 3. This series lathe machine is mainly used for turning the internal and external cylindrical surface, conical surface and other rotating surfaces, as well as turning various type of threads etc.Main Features:
1. One -piece bed adopts high strength iron to ensure rigidity and precision;
2. Ultrasonic frequency quenched guide-ways ensure good wear-resistance;
3. Carriage and guide-way contact surface use Turcite B to maintain accuracy.
CNC Lathe Machine CK61200/6000 | Specification |
Swing over bed | 2100mm |
Swing over cross slide | 1650mm |
Distance between centers | 6000mm |
Guideway width | 1100mm |
Max.load capacity | 20T |
Spindle bore | 130mm |
Spindle bore taper | 120Metric 120 |
Spindle nose type | 1:30 |
Spindle speed steps | VF:4steps(Option:HYDR:4steps) |
Spindle speed range | 2-200rpm |
Chuck | 4-jaw manual 1600mm |
Turret/tool post | Electric turret 4 position |
Tool shank size | 50×50mm |
X axis travel | 850mm |
Z axis travel | 6000mm |
X axis rapid traverse | 4000mm/min |
Z axis rapid traverse | 6000mm/min |
Tailstock quill diameter | Φ280mm |
Tailstock quill taper | 1:07 |
Tailstock quill travel | 300mm |
Main spindle motor | 55KW |
Coolant pump motor | 0.25KW |
Machine size | 6700-13700×2900×2900mm |
Net weight | 29.5T |
Detailed Images
Company Profile
Customers' Feedback
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
