Product Description
Heavy vertical lathe CX5112
The vertical lathe machine is for heavy metal cutting;
DRO is included.
Table dia. |
1000mm |
Max. turning dia. |
1250mm |
Max. workpiece height |
1000/1200/1400mm |
Max. workpiece weight |
3.2t |
Table speed range |
6.3-200 r/min |
Table rotation speed step |
16 |
Vertical toolpost feed range |
0.8-86 r/min |
Vertical side toolpost feed step |
12 |
Horizontal travel of vertical toolpost |
700mm |
Vertical travel of vertical toolpost |
650mm |
Horizontal travel of side toolpost |
500mm |
Vertical travel of side toolpost |
900mm |
Crossam ram travel |
650/850/1050mm |
Tool bar section size(Lx W) |
30x40mm |
Main motor power |
22kw |
Feeding motor power |
1.3/1.8kw |
N.W |
9.5t |
Overall size(LXWXH) |
2277x2540x3403mm |
