CK50T Cnc Slant Bed CNC Lathe Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CK30L Mini Slant CNC Lathe Machine Price for Hobby and EducationNegotiableMOQ: 1 -
CK6125SX450 Horizontal CNC Lathe Machine For School Education and Hobby UsersNegotiableMOQ: 1
-
CK6166 Siemens 808DA Cnc Control System Horizontal Cnc Lathe From China Factory With High PrecisionNegotiableMOQ: 1
-
SHL400/250 Horizontal Cnc Torno Machines Slant Bed Lathe 8-station Servo TurretNegotiableMOQ: 1
-
China Professional Supplier Parallel Lathe SWL550/400 35-degree Slant Bed CNC Lathe Machine for SaleNegotiableMOQ: 1
Specification |
unit |
CK50T |
||||||||||
Maximum swing over the bed |
mm |
550 |
||||||||||
Maximum swing over the carriage |
mm |
320 |
||||||||||
Maximum turning diameter(disk/plate) |
mm |
550/320 |
||||||||||
Maximum turning length |
mm |
630(live center)700(dead center) |
||||||||||
Repeat positioning accuracy |
0.007 |
|||||||||||
Hollow hydraulic chuck size |
10" |
|||||||||||
Spindle head type |
A2-8 |
|||||||||||
Spindle bore |
mm |
93 |
||||||||||
Maximum rod size |
mm |
75 |
||||||||||
Spindle motor power |
Kw |
15(servo) |
||||||||||
Maximum spindle speed |
r/min |
3000 |
||||||||||
Axial travel X/Z |
mm |
230/700 |
||||||||||
Fast feed speed X/Z |
m/min |
16/20(GSK)18/24(FANUC) |
||||||||||
Motor torque X/Z |
Nm |
15/15 |
||||||||||
Screw type X/Z |
mm |
4008/4010 |
||||||||||
Roller heavy loaded linear guideway |
45/45 |
|||||||||||
Toopost position |
12 position |
|||||||||||
Cutter size |
mm |
25x25 |
||||||||||
Maximum bore rod diameter |
mm |
40 |
||||||||||
Tailstock sleeve diameter |
mm |
90 |
||||||||||
Tailstock sleeve stroke |
mm |
100 |
||||||||||
Tailstock sleeve taper |
MT5 |
|||||||||||
Machine overall size (length x width X height) |
mm |
3200x1755x2170 |
||||||||||
Machine net weight |
Kg |
6000 |
||||||||||
