WMTCNC CX5116 Heavy Cutting Vertical Lathe Machine With CE

WMTCNC CX5116 Heavy Cutting Vertical Lathe Machine With CE thumbnail-3

WMTCNC CX5116 Heavy Cutting Vertical Lathe Machine With CE thumbnail-4

WMTCNC CX5116 Heavy Cutting Vertical Lathe Machine With CE photo-1

WMTCNC CX5116 Heavy Cutting Vertical Lathe Machine With CE photo-2

WMTCNC CX5116 Heavy Cutting Vertical Lathe Machine With CE photo-3

WMTCNC CX5116 Heavy Cutting Vertical Lathe Machine With CE photo-4

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Business Type:

Manufacturer

Year Established:

2018

Factory Size:

Below 1,000 square meters

Contact Supplier Request Quote Chat Now

Jingjiang Fuji Technology Co., Ltd.

4Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Description

Main Features:

1. Conventional vertical lathe machine with single column;

2. Rigid column and stable;

3. DRO optional;

4. Precise cutting for heavy metal parts.

Specification	C5116D
Table dia.	1400mm
Max. turning dia.	1600mm
Max. workpiece height	1000/1200/1400/1600mm
Max. workpiece weight	5t
Table speed range	5-160r/min
Table rotation speed step	16
Vertical toolpost feed range	0.8-86 r/min
Vertical side toolpost feed step	12
Horizontal travel of vertical toolpost	915mm
Vertical travel of vertical toolpost	800/1000mm
Horizontal travel of side toolpost	650mm
Vertical travel of side toolpost	1000mm
Crossam ram travel	850/1050/1250/1450mm
Tool bar section size(Lx W)	30x40mm
Main motor power	30kw
Feeding motor power	1.3/1.8kw
N.W	12.7t
Overall size(LXWXH)	2662x2800x3550mm

Detailed Images

Packing & Delivery

Company Profile

Professional Service

Customers' Feedback

FAQ

Q1: How is the warranty?

A1: Warranty time is 13 months after BL date.

Q2: Can we visit your factory before order?

A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3: Do you have a stock?

A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4: What’s the MOQ?

A4: One set only.

Q5: How about your quality?

A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6: Do you have professional engineers?

A6: Yes.we have professional engineers and designers. We can provide OEM services.

Q7: Can you provide customized machines?

A7: Yes, we can design and manufacture according to your specific requirements.
