CK6150 X1000 Length Torno CNC for Threads Making
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Desktop Cnc Lathe CNC180 Mini Cnc Lathe Machine for Education and Hobby UseNegotiableMOQ: 1 -
CK50T Cnc Slant Bed CNC Lathe MachineNegotiableMOQ: 1
-
CK30L Mini Slant CNC Lathe Machine Price for Hobby and EducationNegotiableMOQ: 1
-
CK6125SX450 Horizontal CNC Lathe Machine For School Education and Hobby UsersNegotiableMOQ: 1
-
CK6166 Siemens 808DA Cnc Control System Horizontal Cnc Lathe From China Factory With High PrecisionNegotiableMOQ: 1
Technology Data
Main Feature for CK6150 CNC Lathe for threads making
High rigidity casting bed
High precision spindle bearing
Bed guideways industively hardened
Specification |
CK6150X1000 |
Max.swing over bed |
Ф500mm |
Max.swing over carriage |
Ф280mm |
Max. cutting length |
750/1000/1500mm |
Rail width |
400mm |
Spindle nose |
A2-8 |
Spindle bore |
Ф82mm or Ф86mm;Optional Ф105mm |
Taper of spindle bore |
MT6 |
Chuck size |
10" |
Range of spindle speed |
150-1600rpm or 3 steps:30-150,,10-500,150-1600rpm |
X-axis travel |
330mm |
Z-axis travel |
750/1100/1500mm |
X/Z rapid speed |
5/8m/min |
X/Z screw |
3206/5010 |
Electronic turret |
4 or 6 or 8 |
Max.section of tool |
25x25mm |
Stroke of tailstock sleeve |
150mm |
Diameter/Hole of tailstock sleeve |
Ф75mm/MT4 |
Main motor power |
7.5kw or 11kw |
Coolant pump power |
180w |
Overall dimensions L x W x H |
2100/2420/2860/3320x1600x1830mm |
Packing size L x W x H |
2300/2620/3060/3520x1800x2030mm |
Net weight |
2700/2750/3100/3350kg |
Gross weight |
2600/3000/3450/3650kg |
Standard Accessories:
Cooling system
Auto-lubricating system
Work lamp
GSK-980TDc controller with feeding servo motor
4-Position electrical tool post
Unitary iron casting machine stand
Manual 3-jaw chuck
Optional Accessories:
GSK218M controller
Simens 808D controller
Simens 808D Advance controller
Fanuc Oi TF controller
6/8-Position electrical tool post
Hydraulic chuck
Bar Auto-feeding (KT-16 and KT-20)
