DVT5225 Vertical Type Manual Lathe Machine With Double Column
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CK5116 Hevay Vertical CNC Lathe Machine for Metal CuttingNegotiableMOQ: 1 -
DVT5240C Double Column Heavy Metal Cutting Vertical Lathe Machine With CENegotiableMOQ: 1
-
CK6180 Heavy Duty Horizontal CNC Metal Lathe Machine for SaleNegotiableMOQ: 1
-
CK6150 82mm Spindle Bore Horizontal Cnc Lathe Machine With GSK980TDC SystemNegotiableMOQ: 1
-
C5112D Heavy Duty Vertical Manual Lathe Machine for Metal CuttingNegotiableMOQ: 1
Product Description
Conventional vertical lathe machine with single column;
Rigid column and stable;
DRO optional;
Precise cutting for heavy metal parts.
Name |
Unit |
DVT5225 |
Max. cutting diameter of workpiece |
mm |
2500 |
Workbench diameter |
mm |
2250 |
Max. height of workpiece |
mm |
1600 |
Max. weight of workpiece |
t |
10 |
Workbench speed range |
r/min |
2~63 |
Workbench speed series |
step |
16 steps |
Max. cutting force of right knife rest |
kn |
35 |
Max. cutting force of left knife rest |
kn |
30 |
Max. workbench torque |
kn.m |
63 |
Feeding rang of kinfe rest |
mm/min |
Variable speed |
Rapid movement speed of toolpost |
mm/min |
Variable speed |
Beam movement speed |
mm/min |
350 |
Turning angle of vertical slide |
30 |
|
Knife carrier size(W*H) |
mm |
40x50 |
Main motor power |
kw |
DC55 |
Machine dimensions(L*W*H) |
mm |
5180X5200X4870 |
Detailed Images
Certificate
Packing & Delivery
