Help CenterSkid-mounted Evaporator 380V 60Hz, 1500L/H, 316 Stainless Steel, Heat Exchanger Type, Automatic Drainage
Product Spotlights
Related Products
-
Compact Skid-mounted Evaporator With 316L Stainless Steel, Temperature Control, 380V 3-Phase, 1000L/HUS$ 2700 - 855000MOQ: 1 Combo -
Skid-mounted Evaporator With Factory Warranty, Mill Test Report, 304 SS, PLC Control, 200L/H, CE Standard CompliantUS$ 2700 - 855000MOQ: 1 Combo
-
≥0.5t/H Skid-mounted Forced Circulation Double-effect MVR Crystallization EvaporatorUS$ 830 - 738000MOQ: 1 Combo
-
Skid-mounted MVR Evaporation Equipment for Mother Liquor Drying SystemUS$ 7480 - 65800MOQ: 1 Combo
-
Skid-mounted MVR Evaporation System Falling Film Water EvaporatorUS$ 3900 - 78400MOQ: 1 Combo
As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we are proud to present our Skid-mounted Evaporator 380V 60Hz, 1500L/H, 316 Stainless Steel, Heat Exchanger Type, Automatic Drainage. This evaporator is engineered to deliver high-efficiency concentration and separation for various industrial liquid streams, combining robust construction with intelligent automation. With over 8 years of manufacturing experience and a factory spanning 10,000-30,000 square meters, we ensure every unit meets stringent quality standards, supporting your production with reliable performance and low maintenance requirements.
Our skid-mounted design allows for easy installation and mobility, while the 316 stainless steel construction guarantees excellent corrosion resistance and long service life even in harsh environments. The heat exchanger type evaporator utilizes advanced thermal transfer technology to maximize energy efficiency, and the automatic drainage system minimizes manual intervention, reducing labor costs and operational risks. Whether you are treating industrial wastewater, concentrating chemical solutions, or processing food ingredients, this evaporator delivers consistent results with precise control.
Backed by our annual export value of US$10-50 million, we serve clients across North America, South America, Europe, Southeast Asia, Africa, and Oceania. Our products are certified to international standards including ISO9001, HACCP, and OHSAS18001, ensuring compliance with global quality and safety requirements. Below, we detail the key features and technical specifications that make this evaporator a smart investment for your business.
Key Features & Benefits
- High Evaporation Capacity: 1500 L/H throughput ensures efficient processing for medium-to-large scale operations, reducing batch time and increasing productivity.
- Superior Material: 316 stainless steel construction provides excellent resistance to chlorides, acids, and alkalis, ideal for corrosive feed streams.
- Energy-Efficient Heat Exchanger: Designed with optimized heat transfer surfaces, lowering energy consumption per liter of evaporated water.
- Automatic Drainage System: PLC-controlled automatic drainage prevents scale buildup and ensures continuous operation without manual cleaning.
- Skid-Mounted Compact Design: Pre-assembled on a heavy-duty skid, reducing installation time and footprint; easy to relocate as needed.
- User-Friendly Control: Intuitive HMI touchscreen interface allows operators to monitor temperature, pressure, flow rate, and alarm status in real time.
- Low Maintenance Requirements: Modular construction with accessible components simplifies routine checks and reduces downtime.
- Compliance with Safety Standards: Equipped with safety valves, over-temperature protection, and emergency stop functions, meeting OHSAS18001 guidelines.
Technical Specifications
| Evaporation Capacity | 1500 L/H (at standard conditions) |
| Power Supply | 380V / 60Hz, 3-phase (other voltages available upon request) |
| Material of Construction | 316 Stainless Steel (wetted parts) |
| Heat Exchanger Type | Shell-and-tube heat exchanger, option for plate heat exchanger |
| Drainage System | Automatic drainage with level sensors and solenoid valves |
| Operating Temperature | Up to 120°C (customizable for higher temperatures) |
| Control System | PLC + HMI touchscreen, remote monitoring optional |
| Dimensions (L×W×H) | Approx. 3000×1500×2000 mm (skid-mounted) |
| Weight | Approx. 1800 kg (depending on options) |
Detailed Description
The skid-mounted evaporator is specifically designed for continuous or batch concentration of liquid solutions. The 316 stainless steel construction ensures that the unit can handle aggressive media such as saline wastewater, organic solvents, and acidic streams without degradation. The heat exchanger type evaporator utilizes a shell-and-tube configuration (optional plate heat exchanger) to provide efficient heat transfer, with hot water or steam as the heating medium. The automatic drainage system is a key feature: it periodically discharges concentrated liquid or condensate based on level or time settings, preventing overflow and reducing operator intervention.
The skid-mounted design integrates all major components—evaporator body, heat exchanger, pumps, control panel, and piping—on a single frame. This simplifies installation: you only need to connect power, feed inlet, and product outlet. The compact footprint saves valuable floor space, and the unit can be relocated easily if your production layout changes. The control system includes a PLC with HMI, allowing operators to set parameters such as target concentration, temperature, and drainage intervals. Real-time data logging and alarm functions enhance process visibility and safety.
This evaporator is suitable for a wide range of industries: wastewater treatment (e.g., reducing volume of industrial effluents), chemical processing (concentrating acids, salts, or solvents), food and beverage (e.g., concentrating fruit juices, milk, or sugar solutions), and pharmaceutical (evaporating herbal extracts or active ingredients). The automatic drainage feature is particularly beneficial for applications where continuous operation is required, as it minimizes downtime for manual cleaning.
We also offer customization options: different heating medium (electric, thermal oil, or steam), additional instrumentation (flow meters, conductivity sensors), and remote monitoring via SCADA. Our engineering team can tailor the evaporator to your specific process requirements, including feed characteristics and desired final concentration. All units are factory-tested before shipment, and we provide comprehensive documentation including P&ID, operation manual, and quality certificates.
Trust & Reliability
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a trusted manufacturer since 2015, with a factory size of 10,000-30,000 square meters and a dedicated team of 201-300 employees. Our annual export value of US$10-50 million reflects our strong presence in global markets, including North America, Europe, Asia, Africa, and Oceania. We are committed to quality management systems, holding certifications such as ISO9001, HACCP, OHSAS18001, and others—ensuring that every product meets rigorous international standards.
We understand that investing in industrial equipment requires confidence. That is why we offer comprehensive after-sales support: spare parts availability, remote technical assistance, and optional on-site commissioning. Our team speaks multiple languages to serve international clients effectively. Shipped from Qingdao Port, we provide safe packaging and timely delivery. With a strong reputation built over years of successful projects, we invite you to contact us for detailed proposals, references, or a factory visit. Choose our skid-mounted evaporator for a reliable, efficient, and long-lasting solution to your concentration needs.
Frequently Asked Questions (FAQ)
-
Q: What is the typical feed concentration range for this evaporator?
A: The evaporator is designed to handle feed concentrations from 2% to 30% total solids. However, the optimal range depends on the specific material. For highly viscous or fouling fluids, we recommend a pre-filtration step. Contact us with your feed characteristics for a customized evaluation. -
Q: Can the evaporator handle viscous or scaling liquids?
A: Yes, the 316 stainless steel construction and automatic drainage system help mitigate scaling issues. For highly scaling liquids, we can add an optional CIP (clean-in-place) system or modify the heat exchanger design. The skid-mounted unit is also available with a scraped surface heat exchanger upon request. -
Q: What power supply options are available besides 380V 60Hz?
A: We can configure the evaporator for 380V 50Hz, 220V 60Hz, 440V 60Hz, or other voltages/frequencies. Please specify your local power supply when ordering. The control panel will be adjusted accordingly. -
Q: How is the automatic drainage system controlled?
A: The automatic drainage system uses level sensors or timers to open solenoid valves at preset intervals. The PLC can be programmed to drain based on product concentration, tank level, or time. Operators can also override the system manually via the HMI. -
Q: What is the expected lifespan of the evaporator?
A: Under normal operating conditions and proper maintenance, the 316 stainless steel evaporator can last 10-15 years or more. Regular inspection of seals, gaskets, and heat exchanger surfaces will extend the service life. We provide a standard warranty of 12 months, with extended warranty options available. -
Q: Is on-site installation and training provided?
A: Yes, we offer optional on-site commissioning and operator training for international clients. Our service engineers can travel to your facility to supervise installation, start-up, and train your staff. Alternatively, we provide detailed manuals and remote video support. -
Q: What certifications does this product comply with?
A: The evaporator is manufactured under ISO9001 quality management system, and components may carry CE or other certifications as requested. Our factory holds multiple certifications including HACCP, OHSAS18001, and ISO14000. Specific certificates can be provided upon request for your project compliance. -
Q: Can I get a sample or trial run before purchase?
A: We can arrange a pilot test using our in-house testing facility or a rental unit for your site. Please contact us with your feed sample to evaluate the evaporation performance. For standard models, we also provide video demonstrations and customer references from similar applications.
