Help CenterSkid-mounted Evaporator With Factory Warranty, Mill Test Report, 304 SS, PLC Control, 200L/H, CE Standard Compliant
Product Spotlights
Related Products
-
≥0.5t/H Skid-mounted Forced Circulation Double-effect MVR Crystallization EvaporatorUS$ 830 - 738000MOQ: 1 Combo -
Skid-mounted MVR Evaporation Equipment for Mother Liquor Drying SystemUS$ 7480 - 65800MOQ: 1 Combo
-
Skid-mounted MVR Evaporation System Falling Film Water EvaporatorUS$ 3900 - 78400MOQ: 1 Combo
-
Prefabricated Skid-Mounted Evaporator for Food & Beverage Processing, CIP CapableUS$ 7200 - 115000MOQ: 1 Combo
-
Turnkey Skid-Mounted Forced Circulation Evaporator With Pre-assembled PipingUS$ 7200 - 115000MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., a professional manufacturer established in 2015 with a factory area of 10,000–30,000 square meters and over 200 employees, proudly presents the Skid-mounted Evaporator. This unit combines reliable 304 stainless steel construction, PLC automation, and a compact skid-mounted design to deliver 200 liters per hour evaporation capacity. It comes with a factory warranty and mill test report, and is built to CE standards, making it a trusted solution for industrial liquid concentration and wastewater treatment.
Our evaporator is engineered for efficiency and durability. The skid-mounted platform allows quick on-site installation, while the PLC control system ensures precise operation and easy monitoring. Whether you are treating chemical wastewater, concentrating food products, or recycling industrial liquids, this equipment offers consistent performance and low maintenance.
Key Features & Technical Specifications
- 304 Stainless Steel Construction – Corrosion-resistant and hygienic, suitable for food-contact and harsh chemical environments.
- PLC Control System – Automatic start/stop, temperature, pressure, and level control with touch-screen interface.
- Skid-mounted Design – Pre-assembled on a steel frame, reduces installation time and labor costs.
- 200 L/H Capacity – Ideal for small to medium-scale industrial applications.
- CE Standard Compliance – Meets European safety and performance requirements.
- Factory Warranty – Comprehensive coverage for parts and labor, ensuring peace of mind.
- Mill Test Report Included – Certifies material composition and quality of the 304 SS used.
- Modular Expandability – Optional add-on modules for heat recovery or multi-effect configuration.
| Evaporation Capacity | 200 L/H (at standard conditions) |
| Material of Construction | 304 Stainless Steel (contact parts) |
| Control System | PLC with HMI touch screen |
| Mounting | Skid-mounted, pre-piped and wired |
| Power Supply | 380V / 50Hz (customizable upon request) |
| Operating Temperature | Up to 100°C (dependent on application) |
| Warranty | 1 year factory warranty (extendable) |
| Compliance | CE standard compliant |
Detailed Product Introduction
The skid-mounted evaporator is designed for efficient liquid concentration and volume reduction. Its 304 stainless steel body provides excellent resistance to corrosion, ensuring long service life even when processing acidic or salty solutions. The PLC automation system allows operators to set parameters such as temperature, vacuum level, and feed rate, and the system will maintain them automatically. This reduces human error and improves consistency.
The skid-mounted structure integrates all major components – evaporator vessel, condenser, pump, control panel, and piping – onto a single frame. This eliminates the need for on-site assembly of individual parts, cutting installation time by up to 70% compared to traditional installations. The unit is also easy to relocate, making it suitable for temporary or multi-site operations.
With a capacity of 200 L/H, this evaporator is a perfect fit for batch processing in small to medium factories. It can handle a variety of feed streams, including wastewater from plating, textile, or pharmaceutical industries, as well as concentration of fruit juices, dairy products, or sugar solutions. The mill test report, provided with each unit, certifies that the 304 stainless steel meets ASTM standards, giving you full traceability.
Safety features include over-temperature protection, pressure relief valves, and emergency stop, all integrated into the PLC logic. The touch screen displays real-time data such as evaporation rate, temperature, and pump status, allowing operators to quickly identify any anomalies. Optional remote monitoring via Ethernet is available upon request.
Why Choose This Skid-mounted Evaporator?
- Lower Total Cost of Ownership – Reduced installation cost, high energy efficiency (optional heat recovery module), and low maintenance.
- Proven Reliability – Over 200 units shipped globally since 2015, with positive feedback from clients in North America, Europe, and Southeast Asia.
- Customizable Options – We can adjust capacity, material (316 SS, duplex), control interface, and add CIP (clean-in-place) system according to your process.
- After-sales Support – Our technical team provides online troubleshooting, spare parts supply, and on-site service if needed.
Frequently Asked Questions
-
Q: What is the evaporation temperature range?
A: The operating temperature depends on the vacuum level and the nature of your liquid. Typically, it can be set between 40°C and 100°C. For heat-sensitive products, we can design a low-temperature vacuum evaporation system. -
Q: Is the machine suitable for corrosive liquids?
A: Yes, the standard 304 stainless steel resists many corrosive media. For extremely aggressive chemicals like hydrochloric acid, we recommend 316L or other alloys – please consult our sales team. -
Q: Does the warranty cover all parts?
A: The factory warranty covers manufacturing defects in materials and workmanship for one year. Consumables like seals and gaskets are covered for 90 days. Extended warranty is available. -
Q: Can I get a mill test report before shipment?
A: Yes, the mill test report is included with every evaporator. It certifies the chemical composition and mechanical properties of the 304 stainless steel used. -
Q: What power supply is required?
A: The standard version operates on 380V/50Hz three-phase. We can customize the voltage and frequency (e.g., 220V/60Hz) to match your local grid. -
Q: How long does installation take?
A: Since the unit is skid-mounted and pre-tested, installation typically takes 1–2 days, including connecting utility lines and commissioning. Detailed manual is provided. -
Q: Is training provided?
A: We offer free online training for your operators. On-site training can be arranged at additional cost. -
Q: What kind of after-sales service do you offer?
A: Qingdao Conqinphi has a dedicated after-sales team available via email, phone, or video call. Spare parts can be shipped within 24 hours for in-stock items.
As a manufacturer with an annual export value of US$10–50 million and a factory spanning over 10,000 square meters, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has supplied reliable evaporation solutions to clients across North America, Europe, Asia, and Africa. Our quality management system is certified under ISO9001, and we adhere to strict production standards. Each evaporator undergoes rigorous testing before leaving the factory, ensuring you receive a dependable machine.
Contact us today to discuss your specific application, request a quotation, or schedule a factory visit. Our experienced engineers are ready to customize the skid-mounted evaporator to meet your exact requirements. With factory warranty, mill test report, and CE compliance, you can invest with confidence.
