Rugged Skid-Mounted Evaporator for Mining Effluent, Designed for Harsh Environments
Product Spotlights
A pre-assembled, skid-mounted evaporator built for extreme durability in mining effluent treatment. Features corrosion-resistant construction for harsh chemistries, plug-and-play installation to slash on-site time/costs, high energy efficiency, and intelligent PLC automation. Customizable for various heat sources and capacities, it delivers reliable volume reduction, water recovery, and compliance in remote locations.
US$ 7200 - 115000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Application:
Other, Mining Effluent Treatment
Mounting Type:
Skid-Mounted
Design Environment:
Harsh / Rugged Conditions
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days
Related Products
-
Automatic Skid-Mounted MVR Evaporator for Wastewater Treatment With 304L ConstructionUS$ 7200 - 115000MOQ: 1 Combo -
Compact Skid-Mounted Falling Film Evaporator System for Pharmaceutical ConcentrationUS$ 7200 - 115000MOQ: 1 Combo
-
Skid-Mounted Thermal Evaporator for Metal Finishing Rinse Water, 500 GPH CapacityUS$ 7200 - 115000MOQ: 1 Combo
-
Skid-Mounted Evaporator Crystallizer Unit for Salt Recovery, PLC ControlledUS$ 7200 - 115000MOQ: 1 Combo
-
≥0.5t/H Skid-mounted Forced Circulation Double-effect MVR Crystallization EvaporatorUS$ 830 - 738000MOQ: 1 Combo
Application
Other, Mining Effluent Treatment
Mounting Type
Skid-Mounted
Design Environment
Harsh / Rugged Conditions
Construction Material
Corrosion-Resistant Alloy / Stainless Steel
Standard Compliance
ISO 9001, ISO 14001, OHSAS 18001
Portability
Pre-assembled for Easy Transport & Installation
Control System
Programmable Logic Controller (PLC) Based
Heat Source
Optional (Steam, Electric, Thermal Oil)
Capacity Range
Customizable based on effluent flow rate
As a leading manufacturer with a decade of expertise in environmental technology, Qingdao Conqinphi Environmental Technology Group proudly presents our Rugged Skid-Mounted Evaporator, engineered specifically for the demanding task of mining effluent management. Operating from our expansive 10,000-30,000 sqm facility with a dedicated team of over 200 professionals, we understand the critical need for reliable, robust solutions in remote and harsh mining sites. This evaporator embodies our commitment to delivering high-performance equipment that addresses complex industrial wastewater challenges, helping clients achieve regulatory compliance, recover valuable resources, and minimize environmental impact efficiently and cost-effectively.
This evaporator is not just a piece of equipment; it's a complete, pre-engineered solution designed for operational readiness in the most challenging environments.
- Unmatched Durability: Constructed from premium, corrosion-resistant materials such as stainless steel 316L or specialized alloys, the unit is built to withstand the highly abrasive, acidic, or alkaline nature of mining effluent, ensuring a long service life even under constant exposure.
- Skid-Mounted Advantage: The entire system is pre-assembled, piped, wired, and tested on a single, robust skid frame at our factory. This revolutionary approach drastically reduces on-site installation time and costs, minimizes commissioning risks, and allows for quicker deployment to remote locations.
- Engineered for Harsh Conditions: From extreme temperatures to dusty, high-vibration settings, every component is selected and protected. Features may include sealed electrical enclosures (IP65/IP66 rated), reinforced structural supports, and climate-proof insulation to guarantee uninterrupted operation.
- High-Efficiency Evaporation: Utilizing advanced thermal design, the system maximizes heat transfer efficiency, significantly reducing energy consumption per unit of water evaporated. This translates directly into lower operational costs for our clients.
- Intelligent Automation & Control: Equipped with a state-of-the-art PLC-based control system, the evaporator offers automated operation, real-time monitoring of key parameters (temperature, pressure, level, concentration), and remote access capabilities for enhanced safety and minimal manual intervention.
- Flexible Configuration: The system can be tailored to various heat sources available on-site, including waste steam, electric heating, or thermal oil. Capacity is fully customizable to match specific effluent flow rates and concentration requirements.
The technical prowess of our evaporator is reflected in its precise engineering and adaptable specifications.
| Parameter Category | Specification / Description |
|---|---|
| Design Principle | Forced Circulation or Falling Film Evaporation (configurable) |
| Standard Construction Material | Stainless Steel 304/316L, Duplex Steel, or other corrosion-resistant alloys |
| Heat Exchange Surface | Customizable area based on capacity requirement |
| Operating Pressure | Vacuum to Atmospheric (designed for optimal energy efficiency) |
| Control System | PLC with HMI Touchscreen, featuring data logging and alarm management |
| Utility Connections | Pre-fitted interfaces for steam/electricity, cooling water, feed, and condensate |
| Skid Dimensions & Weight | Optimized for standard container transport; specifics provided per model |
Choosing our Rugged Skid-Mounted Evaporator delivers concrete benefits:
- Reduced Capex & Opex: Lower installation costs and higher energy efficiency lead to a favorable return on investment.
- Water Recovery & Minimized Discharge: Significantly reduces effluent volume, facilitating water reuse and easing discharge compliance burdens.
- By-Product Concentration: Allows for the recovery of valuable salts or metals from the concentrated brine, potentially creating an additional revenue stream.
- Operational Reliability: Factory testing and robust design ensure high availability and reduce unplanned downtime.
- Scalability: Modular design allows for future capacity expansion as mining operations grow.
Backed by Qingdao Conqinphi's strong manufacturing foundation—evidenced by our ISO 9001 quality management, ISO 14001 environmental management, and OHSAS 18001 occupational health safety certifications—and an annual export value reaching up to US$50 Million, you can trust in the reliability and global acceptance of our products. Our equipment is shipped worldwide from the Port of Qingdao, serving major markets across six continents. We combine proven engineering with a deep understanding of mining sector challenges to deliver a solution that performs. Don't let effluent management slow down your operations; contact us today to discuss how our rugged, skid-mounted evaporator can be customized to meet your specific site requirements and drive your project's success.
Frequently Asked Questions (FAQ)
-
Q: What are the main advantages of a skid-mounted design over a traditional field-erected system?
A: The skid-mounted design offers superior cost and time efficiency. It arrives pre-assembled and tested, requiring only utility hookup and minimal civil work on-site. This reduces installation time by weeks or months, lowers labor costs, and ensures system integrity through factory quality control. -
Q: Can this evaporator handle the specific chemistry of my mining effluent, which may be high in sulfates or chlorides?
A: Absolutely. A key part of our design process is a detailed analysis of your feed composition. We select construction materials (like high-grade stainless steel or specialized alloys) specifically to resist corrosion from sulfates, chlorides, and other aggressive ions present in your effluent stream. -
Q: What kind of energy source is required to operate the evaporator?
A: Our systems are highly flexible. They can be designed to utilize various heat sources commonly available at mining sites, such as waste/low-pressure steam, electric heaters, or thermal oil. We will engineer the optimal solution based on your site's available utilities. -
Q: How is the concentrated brine or slurry handled after evaporation?
A> The system is designed to produce a concentrated slurry or solid cake. This output can be directed to further dewatering equipment (like a filter press) for solidification, or stored in designated tanks for disposal or resource recovery, depending on your site's process flow. -
Q: What level of automation and remote monitoring is included?
A> The standard package includes a fully automated PLC control system with a user-friendly touchscreen HMI. It allows for automated start/stop sequences, parameter monitoring, and alarm handling. Remote monitoring options are available, enabling oversight from a central control room. -
Q: How do you ensure the unit will perform reliably in a remote, harsh location with limited maintenance access?
A> Reliability is built into the design. We use heavy-duty components, provide comprehensive protection for electrical systems (IP ratings), and design for ease of maintenance. Furthermore, thorough factory acceptance testing (FAT) ensures the unit is fully operational before shipment, and we offer detailed operation & maintenance manuals and training. -
Q: Is the capacity fixed, or can it be adjusted for future expansion?
A> Our designs often incorporate scalability. We can provide modular units that allow for capacity increases in the future, or design the initial system with some overhead to accommodate moderate flow increases. -
Q: What is the typical lead time for such a customized skid-mounted evaporator?
A> Lead time varies based on the complexity, capacity, and material specifications. Generally, for standard designs, it ranges from 16 to 24 weeks from order confirmation to ex-works readiness. A more precise timeline will be provided upon receipt of your detailed project requirements.
