Skid-Mounted Evaporator for Food Industry Juice Concentration With 1 Year Warranty and Mill Test Report
Product Spotlights
Pre-assembled, factory-tested skid-mounted evaporator designed for fruit juice concentration. Includes 1-year warranty and Mill Test Report. Modular design reduces installation time, low-temperature vacuum operation preserves juice quality, high-efficiency heat transfer lowers energy costs. Options for CIP, PLC control, and various capacities (500–5000 kg/h).
US$ 32600 - 875000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Material:
Other, Stainless Steel 304/316 (optional)
Warranty:
1 year
evaporation capacity:
500-5000 kg/h (customizable)
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
15 days
Related Products
-
304 Stainless Steel Skid-Mounted Evaporator With PLC Control for Industrial Wastewater TreatmentUS$ 32600 - 875000MOQ: 1 Combo -
Skid-Mounted Evaporator for Zero Liquid Discharge in Oil & Gas Field Brine ConcentrationUS$ 32600 - 875000MOQ: 1 Combo
-
PLC Controlled Skid-Mounted Evaporator 380V 3-Phase 50Hz With Touch Screen InterfaceUS$ 32600 - 875000MOQ: 1 Combo
-
220V 15kW Skid-Mounted Evaporator With Automatic Feed System and IP65 EnclosureUS$ 32600 - 875000MOQ: 1 Combo
-
Skid-Mounted Evaporator With Free Installation Training and 24-Month Warranty for Overseas ClientsUS$ 32600 - 875000MOQ: 1 Combo
Material
Other, Stainless Steel 304/316 (optional)
Warranty
1 year
evaporation capacity
500-5000 kg/h (customizable)
power consumption
kW varies per model (contact for details)
working temperature
60°C – 100°C (adjustable)
working pressure
Atmospheric or vacuum (customizable)
skid dimensions
L x W x H customized per capacity
applications
Juice concentration, dairy, beverage, etc.
control system
PLC with touch screen (optional)
At Qingdao Conqinphi Environmental Technology Group Co., Ltd. (established 2015, 10,000-30,000 sqm factory, US$10M-50M annual export), we engineer robust skid-mounted evaporators specifically designed for food industry juice concentration. Our unit offers a turnkey solution that integrates evaporation, condensation, and separation in a compact, pre-assembled frame, saving installation time and reducing on-site welding. Backed by a 1-year warranty and accompanied by a Mill Test Report (MTR), this evaporator delivers reliable performance for concentrating fruit juices while preserving flavor and nutrients.
Key Features & Technical Advantages:
- Pre-mounted skid design – Factory assembled, tested, and ready for quick connection to utilities, minimizing field labor.
- High-efficiency heat transfer – Utilizing falling film or forced circulation technology (option) to achieve high evaporation rates with low energy consumption.
- Hygienic construction – All product-contact surfaces in 304 or 316 stainless steel, with mirror polish (Ra ≤ 0.6μm) to meet food safety standards.
- Gentle juice concentration – Low temperature operation under vacuum reduces thermal damage, retaining natural sugars, acids, and aroma.
- Automated controls – Integrated PLC with HMI for monitoring temperature, pressure, flow, and density; alarm system for safe operation.
- Flexible capacity – Evaporation rates from 500 kg/h to 5000 kg/h, customizable based on customer’s concentration requirements.
- Complete auxiliary package – Includes condenser, vacuum pump, product pump, CIP nozzles, and framework – all within the skid.
- Mill Test Report – Detailed material and performance documentation provided for each unit, ensuring traceability and quality assurance.
Specification Table (Typical Model JSA-2000):
| Parameter | Value |
| Evaporation rate (water) | 2000 kg/h |
| Operating temperature | 65–85 °C (adjustable) |
| Vacuum degree | –0.08 MPa (optional) |
| Heating medium | Saturated steam (0.3–0.6 MPa) |
| Power supply | 380V/50Hz (customize available) |
| Skid footprint | 5.0m × 2.5m × 3.5m (approx.) |
| Material | SS304 / SS316 (food-grade) |
| Warranty | 1 year |
| Included documentation | Mill Test Report, O&M manual |
How This Evaporator Benefits Your Juice Production:
- Space saving: All components mounted on a single base – no need for separate supports.
- Fast commissioning: Pre-wired and pre-piped; connect utilities and start within 2 days.
- Energy efficient: Vapor recompression option can reduce steam consumption by up to 30%.
- Easy cleaning: Built-in CIP nozzles allow automatic cleaning of all product-contact surfaces.
- Consistent product quality: Precise vacuum control minimizes boiling point, preventing burn-on and preserving vitamins.
- Low maintenance: All pumps and sensors are standard industrial parts, easily replaceable.
With more than 200 skilled employees and a factory area of over 10,000 square meters, Qingdao Conqinphi Environmental Technology Group has exported to markets across North America, South America, Europe, Southeast Asia, Africa, and Oceania. Our quality management system is certified to ISO9001, ISO14000, HACCP, and others, ensuring every evaporator meets strict manufacturing and food safety standards. Request a quotation today and let our technical team customize the perfect skid-mounted evaporator for your juice concentration line. All units come with a 1-year warranty and Mill Test Report as standard.
Frequently Asked Questions:
-
Q: What is a Mill Test Report (MTR)?
A: The MTR is a quality document that certifies the material composition and mechanical properties of the stainless steel used in the evaporator. It provides full traceability from the mill to your equipment. -
Q: Can this evaporator handle high-sugar juices like apple or grape?
A: Yes. Our design can operate with high viscosity and high sugar content. Falling film technology with proper recirculation ensures efficient concentration without fouling. -
Q: What is the typical lead time?
A: For standard models, lead time is 30–45 days after down payment. Custom capacities may take 50–60 days. Please contact us for exact timing. -
Q: Do you provide installation supervision?
A: Yes, we offer on-site commissioning service by our experienced engineers (travel cost & fee apply). Detailed manuals and remote support are also available. -
Q: Is the skid evaporator suitable for CIP (Clean-in-Place)?
A: Absolutely. The system is designed with dedicated CIP inlet/outlet and spray devices inside the tubes and separator, allowing automated cleaning cycles. -
Q: What is the warranty coverage?
A: Warranty covers manufacturing defects in materials and workmanship for 12 months from the date of shipment. Consumable parts like seals and gaskets are excluded. -
Q: Can I get a customized voltage or frequency?
A: Yes. We can design the electrical system to match your local power supply, including 60 Hz, 440V, 230V, etc. Please specify in your inquiry. -
Q: Do you have references in the juice industry?
A: Yes, we have supplied similar systems to fruit processing plants in Brazil, Thailand, and Europe. References can be provided upon request.
