Help CenterCompact Skid-mounted Evaporator With 316L Stainless Steel, Temperature Control, 380V 3-Phase, 1000L/H
Product Spotlights
Related Products
-
Skid-mounted Evaporator With Factory Warranty, Mill Test Report, 304 SS, PLC Control, 200L/H, CE Standard CompliantUS$ 2700 - 855000MOQ: 1 Combo -
≥0.5t/H Skid-mounted Forced Circulation Double-effect MVR Crystallization EvaporatorUS$ 830 - 738000MOQ: 1 Combo
-
Skid-mounted MVR Evaporation Equipment for Mother Liquor Drying SystemUS$ 7480 - 65800MOQ: 1 Combo
-
Skid-mounted MVR Evaporation System Falling Film Water EvaporatorUS$ 3900 - 78400MOQ: 1 Combo
-
Prefabricated Skid-Mounted Evaporator for Food & Beverage Processing, CIP CapableUS$ 7200 - 115000MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our Compact Skid-mounted Evaporator crafted from premium 316L stainless steel. Designed for demanding industrial environments, this unit delivers reliable 1000L/H evaporation capacity with integrated temperature control and 380V 3-phase power. Its compact, pre-assembled skid design simplifies installation and reduces on-site labor, making it an ideal solution for wastewater concentration, chemical processing, and liquid recovery applications.
Built with corrosion-resistant 316L stainless steel, the evaporator ensures long service life even when handling aggressive media. The advanced temperature control system maintains precise evaporation temperatures, improving energy efficiency and product quality. The 380V 3-phase electrical configuration is compatible with standard industrial power grids worldwide, and the skid-mounted layout allows for easy integration into existing production lines.
Key Product Features
- 316L Stainless Steel Construction – Exceptional resistance to pitting, crevice corrosion, and stress cracking in chloride environments.
- Skid-Mounted Design – Pre-assembled and factory-tested, reducing installation time and footprint.
- Temperature Control System – PID-based automatic regulation ensures stable evaporation temperature (range customizable upon request).
- 380V 3-Phase Power – Efficient electrical design suitable for most industrial sites; frequency 50/60Hz available.
- 1000L/H Evaporation Capacity – Handles medium to large volumes with consistent throughput.
- Low Maintenance – Easy access to heat exchanger, condenser, and control panel for routine servicing.
- Optional Accessories – Feed pump, vacuum system, CIP cleaning unit, remote monitoring available.
| Parameter | Specification |
|---|---|
| Material | 316L Stainless Steel (wetted parts) |
| Evaporation Capacity | 1000 L/H (at standard conditions) |
| Power Supply | 380V 3-Phase, 50/60Hz (customizable) |
| Temperature Control | PID automatic control, accuracy ±1°C |
| Mounting Type | Skid-mounted (compact footprint) |
| Overall Dimensions | Customizable (contact for specific layout) |
| Weight | Approx. 1200 kg (varies with options) |
The evaporator's compact skid design integrates all major components—evaporation chamber, heat exchanger, condenser, and control panel—on a single base frame. This eliminates the need for complex field assembly and reduces the risk of installation errors. The 316L stainless steel construction is specifically chosen for applications involving saline solutions, acids, or chlorides, where standard 304 steel may suffer from rapid corrosion.
Temperature control is critical in evaporation processes to prevent thermal degradation of sensitive products. Our system uses a PLC-based PID controller and a high-accuracy temperature sensor to maintain the set point within ±1°C. This feature not only preserves product quality but also reduces energy consumption by avoiding overheating.
With a 1000L/H evaporation rate, the unit is suitable for medium to large-scale operations in industries such as wastewater treatment, chemical concentration, pharmaceutical manufacturing, and food processing. The 380V 3-phase power supply is standard in most industrial facilities, and optional voltage/frequency configurations are available upon request.
Trust & Experience
As a manufacturer established in 2015, Qingdao Conqinphi Environmental Technology Group Co., Ltd. operates a factory spanning 10,000–30,000 square meters with a dedicated team of 201–300 employees. Our annual export value exceeds US$10 million, serving markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Shipments are directly from the port of Qingdao, ensuring efficient logistics.
We adhere to rigorous quality management systems, holding multiple certifications (including ISO9001, ISO14000, and others) that can be provided upon request. Every evaporator undergoes factory testing before delivery to guarantee performance. Our technical team offers comprehensive after-sales support, including installation guidance, troubleshooting, and spare parts supply.
Choose our compact skid-mounted evaporator for reliable performance, durable materials, and expert support. Contact us today for a customized solution or a quotation.
Frequently Asked Questions (FAQ)
1. What types of liquids can this evaporator handle?
This 316L stainless steel evaporator is suitable for aqueous solutions, chemical mixtures, wastewater, brine, and many industrial process streams. For highly corrosive fluids, please consult our engineering team to verify compatibility.
2. What is the temperature control range?
The standard temperature control range is 40°C to 90°C, but the system can be customized for higher or lower temperatures depending on your specific requirements.
3. Can the evaporator be customized for different voltages or frequencies?
Yes. While the standard configuration is 380V 3‑phase 50/60Hz, we offer optional voltage/frequency settings (e.g., 220V, 440V, 60Hz) — please specify your local power supply when ordering.
4. How much space is needed for installation?
The unit is skid‑mounted and compact. Typical footprint is about 2.5m (L) × 1.5m (W) × 2.2m (H), but final dimensions depend on optional components. Our team can provide a detailed layout drawing for your site.
5. What maintenance is required?
Routine maintenance includes cleaning the heat exchanger surfaces (frequency depends on feed quality), checking seals and gaskets, and calibrating the temperature sensor. An optional CIP (clean‑in‑place) system reduces manual cleaning effort.
6. Does the unit come with a warranty?
We offer a standard one‑year warranty against manufacturing defects. Extended warranty plans are available. Please refer to our terms and conditions for details.
7. What certifications does your company hold?
Our company has been certified under multiple management systems, including ISO9001, ISO14000, OHSAS18001, and others. Specific product certifications can be provided upon request.
8. How long does delivery take?
Standard delivery time is approximately 30–45 days after order confirmation, depending on customization and current production load. For urgent orders, please contact our sales team for expedited options.
