Skid-Mounted Evaporator Crystallizer Unit for Salt Recovery, PLC Controlled
Product Spotlights
A pre-assembled, PLC-controlled skid-mounted system for efficient salt recovery from industrial wastewater. It features a modular design for fast installation, automated operation for consistent output, and corrosion-resistant construction for durability. The unit transforms waste into valuable salt, reducing disposal costs and aiding compliance. It is a cost-effective, reliable solution backed by extensive manufacturing expertise and global export experience.
US$ 7200 - 115000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Application:
Other, Salt Recovery from Industrial Wastewater
Configuration:
Skid-Mounted, PLC Controlled
Control System:
Programmable Logic Controller (PLC)
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days
Related Products
-
≥0.5t/H Skid-mounted Forced Circulation Double-effect MVR Crystallization EvaporatorUS$ 830 - 738000MOQ: 1 Combo -
Skid-mounted MVR Evaporation Equipment for Mother Liquor Drying SystemUS$ 7480 - 65800MOQ: 1 Combo
-
Skid-mounted MVR Evaporation System Falling Film Water EvaporatorUS$ 3900 - 78400MOQ: 1 Combo
-
Prefabricated Skid-Mounted Evaporator for Food & Beverage Processing, CIP CapableUS$ 7200 - 115000MOQ: 1 Combo
-
Turnkey Skid-Mounted Forced Circulation Evaporator With Pre-assembled PipingUS$ 7200 - 115000MOQ: 1 Combo
Application
Other, Salt Recovery from Industrial Wastewater
Configuration
Skid-Mounted, PLC Controlled
Control System
Programmable Logic Controller (PLC)
Design Type
Modular, Pre-assembled Unit
Key Process
Evaporation and Crystallization
Material Construction
Corrosion-Resistant Alloys (e.g., 316L SS)
Installation
Fast, Plug-and-Play Deployment
Customization
Available for Specific Feed Conditions
As a leading manufacturer with over 8 years of expertise in environmental technology, Qingdao Conqinphi Environmental Technology Group is proud to introduce our advanced Skid-Mounted Evaporator Crystallizer Unit for Salt Recovery. Engineered for precision and reliability, this PLC-controlled system represents our commitment to providing turnkey solutions for industrial wastewater treatment and resource recovery. Designed for efficiency and ease of integration, our unit helps clients transform waste streams into valuable salt products, significantly reducing disposal costs and enhancing environmental compliance. Our experience serving global markets across North America, Europe, Asia, and beyond ensures this product is built to meet international operational standards.
Core Product Features & Technical Advantages:
Our skid-mounted evaporator crystallizer is a complete, pre-engineered package designed to simplify complex separation processes. Below are its defining characteristics:
- Integrated Skid Design: The entire evaporation and crystallization system, including pumps, heat exchangers, controls, and piping, is mounted on a single structural steel skid. This modular approach drastically reduces field installation time and costs, minimizes on-site assembly errors, and ensures system integrity.
- Intelligent PLC Control: At the heart of the unit is a sophisticated Programmable Logic Controller. This automation system allows for precise monitoring and control of critical parameters such as temperature, pressure, level, and density. Operators can run pre-set programs, receive alarms, and generate operational reports, ensuring consistent product quality and process stability with minimal manual intervention.
- High-Efficiency Evaporation: The system utilizes forced-circulation or falling-film evaporation technology (customizable based on feed) to efficiently concentrate brine solutions. This design maximizes heat transfer, minimizes energy consumption, and prevents scaling, leading to lower operational expenses.
- Controlled Crystallization: Following evaporation, the supersaturated solution enters the crystallizer where salt crystals are grown under controlled conditions. This results in uniform crystal size distribution, high purity, and easy solid-liquid separation, yielding a marketable salt product.
- Superior Material Selection: Constructed primarily from corrosion-resistant materials like 316L stainless steel or higher-grade alloys for critical wetted parts, the unit is built to handle aggressive brine chemistries and ensure a long service life, reducing maintenance frequency.
- Resource Recovery Focus: The primary benefit is the recovery of high-purity salts (e.g., sodium chloride, sodium sulfate) from industrial wastewater, turning an environmental liability into a potential revenue stream while achieving Zero Liquid Discharge (ZLD) objectives.
Detailed Technical Specifications:
The following table outlines key specifications for a standard model. Parameters can be customized to match specific feed flow rates, concentrations, and target salt types.
| Parameter | Specification / Description |
|---|---|
| Feed Capacity (Customizable) | Range from 1 m³/hr to 50 m³/hr |
| Evaporator Type | Forced Circulation or Falling Film (Selectable) |
| Heat Source | Steam or Thermal Oil (Electric optional) |
| Crystallizer Type | Forced Circulation Oslo or Draft Tube Baffle (DTB) |
| Control System | PLC with Color HMI Touchscreen, Data Logging |
| Construction Material (Main) | 316L Stainless Steel (Higher grades available) |
| Skid Dimensions (Approx.) | Custom designed per capacity; pre-assembled for shipping |
| Key Output | Dry Salt Crystals & Condensed Water |
Tangible Benefits for Your Operation:
- Reduced Capital & Installation Cost: The skid-mounted design eliminates extensive field fabrication. It arrives ready for connection to utilities and feed lines, cutting project timelines by weeks or months.
- Lower Operational Costs: Automated PLC control optimizes energy and chemical usage. High-efficiency thermal design reduces steam consumption. Recovered salt can offset operating expenses.
- Enhanced Process Reliability: Factory testing of the complete unit before shipment ensures all components work harmoniously, reducing startup risks and ensuring predictable performance.
- Simplified Compliance: Achieve stringent wastewater discharge limits or ZLD goals reliably. The system provides a documented, controlled method for waste minimization.
- Operational Flexibility: The PLC system allows for easy adjustment of setpoints and recipes to handle variations in feed quality or to produce different salt specifications.
Backed by Conqinphi's robust manufacturing capabilities in a 10,000-30,000 sqm facility and a track record of exporting to demanding markets worldwide, this Skid-Mounted Evaporator Crystallizer Unit is more than just equipment—it's a partnership in sustainable industrial operation. Our adherence to a comprehensive framework of quality management systems underscores our commitment to delivering durable, high-performance solutions. Choose our unit to gain a reliable, automated, and cost-effective pathway for salt recovery, transforming your wastewater treatment challenge into an opportunity for resource efficiency and regulatory confidence. Contact us today to discuss how we can customize this solution for your specific application.
Frequently Asked Questions (FAQ):
-
Q: What types of wastewater or brine is this unit suitable for?
A: This unit is highly effective for treating saline wastewater from industries like chemical processing, pharmaceuticals, textile dyeing, landfill leachate, and power plant flue gas desulfurization. The specific design (materials, evaporator type) is customized based on your feed's salt composition, concentration, and impurities. -
Q: How does the skid-mounted design benefit international buyers?
A: The pre-assembled, containerized design simplifies logistics, reduces import complexity, and minimizes the need for highly specialized local installation contractors. It ensures you receive a system that has been fully tested and commissioned at our factory, significantly de-risking your project. -
Q: What is the typical lead time for such a unit?
A: Lead time depends on the capacity and customization level. Standard medium-capacity units typically have a lead time of 16-24 weeks from order to shipment, which includes detailed engineering, procurement, fabrication, and comprehensive factory acceptance testing. -
Q: Can the system achieve Zero Liquid Discharge (ZLD)?
A: Yes, this evaporator crystallizer is a core component of a ZLD system. It concentrates the brine to the point of crystallization, producing solid salt and clean water condensate. For complete ZLD, it can be integrated with a downstream dryer or additional concentrator. -
Q: What kind of after-sales support and training do you provide?
A: We provide detailed operation & maintenance manuals, P&ID drawings, and electrical schematics. We offer comprehensive training for your operators at our factory or via online sessions. Remote technical support and a supply of critical spare parts are also available. -
Q: How energy-efficient is this system compared to traditional evaporation ponds?
A: It is substantially more efficient. Mechanical evaporation recycles latent heat and operates in a closed loop, using significantly less energy per kilogram of water evaporated than open ponds, which are subject to high heat losses and large land requirements. -
Q: Is the PLC system user-friendly for operators without extensive programming knowledge?
A: Absolutely. The human-machine interface (HMI) is designed with intuitive graphics, pre-configured recipes, and clear alarm messages. Standard operations like starting, stopping, and monitoring require only basic training. Advanced parameter changes can be password-protected. -
Q: Can you assist with the initial process design and feasibility study?
A: Yes, as a solution provider, we offer preliminary engineering services. We can analyze a sample of your wastewater, conduct lab or pilot tests if needed, and provide a process flow diagram and feasibility report to ensure the system design meets your recovery and purity targets.
