As a leading manufacturer in environmental and process technology, Qingdao Conqinphi Environmental Technology Group is proud to present our advanced Compact Skid-Mounted Falling Film Evaporator System, engineered specifically for the demanding requirements of pharmaceutical concentration. With our foundation built in 2015 and a sprawling manufacturing facility, we combine rigorous quality management systems with innovative engineering to deliver reliable, high-performance evaporation solutions. This system is designed to offer pharmaceutical producers a significant advantage in process efficiency, product quality, and operational flexibility, all within a space-saving, pre-engineered package.
Our evaporator system is built around the highly efficient falling film principle, which is particularly suited for heat-sensitive pharmaceutical products. The core design ensures a thin, uniform film of liquid flows down the interior of heated tubes, allowing for rapid evaporation at lower temperatures and shorter residence times. This minimizes thermal degradation of active pharmaceutical ingredients (APIs) and preserves valuable product characteristics. The entire system is constructed on a single, robust skid, which is pre-assembled, piped, wired, and tested at our factory before shipment. This approach drastically reduces on-site installation time, complexity, and cost, enabling faster project commissioning.
Key Technical Specifications and Advantages:
- Superior Heat Transfer & Product Quality: The falling film design provides a large heat transfer surface area, leading to high evaporation rates. Gentle heating conditions help maintain the integrity, potency, and color of sensitive pharmaceutical solutions.
- Compact & Integrated Skid Design: All major components—including the evaporator body, separator, condenser, vacuum system, pumps, and control panel—are mounted on a single, compact frame. This modular approach saves valuable floor space in cleanrooms or production areas.
- Customizable Construction: The system is typically constructed from high-grade 316L stainless steel for excellent corrosion resistance and cleanability, meeting pharmaceutical hygiene standards. Material choices can be customized upon request.
- Energy Efficient Operation: The system can be configured for multiple-effect operation or with Mechanical Vapor Recompression (MVR) technology, significantly reducing steam consumption and lowering operational energy costs.
- Advanced Process Control: An optional PLC-based automation system allows for precise control over parameters like temperature, pressure, flow rate, and concentration. This ensures batch-to-batch consistency, reduces manual intervention, and facilitates data logging for compliance.
The table below outlines some typical configurable parameters of our system:
| Parameter | Description / Typical Range |
| Evaporation Capacity | Custom designed from 100 kg/hr to several tons per hour |
| Operating Pressure | Vacuum operation (customizable) |
| Heat Source | Saturated steam or thermal oil |
| Final Concentration | Can be precisely controlled as per process need |
| Surface Finish | Electropolished or mechanical polish available |
Frequently Asked Questions (FAQ):
-
Q: What are the main benefits of a skid-mounted design for a pharmaceutical plant?
A: The skid-mounted design offers plug-and-play functionality. It reduces installation time and costs, minimizes on-site welding and potential contamination risks, ensures factory-tested system integrity, and simplifies future relocation or expansion. -
Q: How does the falling film evaporator protect heat-sensitive pharmaceutical materials?
A: It operates with a single-pass, short residence time and under vacuum, which lowers the boiling point. This combination allows for concentration at much lower temperatures compared to other methods, effectively preventing thermal degradation. -
Q: Can this system handle solvents or is it only for aqueous solutions?
A: While excellent for aqueous solutions, the system design can be adapted for solvent recovery or concentration. Special considerations for materials of construction, explosion-proofing, and condenser design would be evaluated during the customization process. -
Q: What level of automation is included?
A: We offer scalable control solutions. A basic system includes essential instrumentation for manual control. For full automation, we provide PLC/SCADA systems with touchscreen HMIs for recipe management, automatic CIP (Clean-in-Place) sequences, and data recording. -
Q: What after-sales support do you provide?
A> Our support includes detailed operation manuals, installation supervision available upon request, remote technical assistance, and a supply of recommended spare parts. We have a global service network to support our exports. -
Q: How is the system cleaned and validated?
A: The system is designed for easy cleaning, often with CIP capabilities. We provide documentation packages (DQ/IQ/OQ) to support our clients' validation processes, which is crucial for pharmaceutical applications. -
Q: What is the typical lead time for a custom system?
A: Lead time varies based on complexity and capacity. For a standard compact design, it generally ranges from 12 to 20 weeks after final design approval. We provide detailed project timelines during the quotation phase. -
Q: Do you offer pilot-scale units for testing?
A: Yes, we can provide smaller pilot or laboratory-scale falling film evaporators. This allows clients to conduct process feasibility studies and scale-up trials with their specific products before investing in a full-scale system.
Backed by a robust manufacturing infrastructure spanning 10,000-30,000 square meters and a dedicated team of 201-300 professionals, Qingdao Conqinphi delivers not just equipment, but reliable process solutions. Our commitment to quality is reflected in our adherence to recognized management standards. We serve a diverse global market, from North America and Europe to Southeast Asia and Africa, ensuring our designs meet international expectations. Choosing our Compact Skid-Mounted Falling Film Evaporator means investing in a system that enhances your pharmaceutical concentration process through improved yield, consistent quality, reduced operational costs, and faster project implementation. Contact us today to discuss how we can tailor this efficient solution to your specific production requirements.
