I. Product Description
This module belongs to the ABB Advant OCS/S100 series of DCS system 8-channel analog output board card. It converts the digital signals issued by the controller into standard industrial voltage and current analog signals, which are used for precisely regulating on-site equipment such as valves, frequency converters, actuators, etc., to achieve closed-loop regulation of process parameters such as temperature, pressure, and flow. It is a rack-mounted plug-in type industrial DCS spare part. Currently, the original factory has discontinued production and is mostly used for replacing old control systems in power plants and chemical industries.
Key Technical Parameters
Channel Configuration: 8 independent isolated analog output channels
Output Signal Range: ±10V voltage, ±20mA current (switchable by software configuration)
D/A Conversion Resolution: 12 bits (including sign bit)
Conversion Accuracy: ±0.2% of full scale
Single Channel Maximum Load: 750Ω (current output condition)
Channel Isolation Level: 1000VAC electrical isolation from ground
Module Power Supply: DC24V industrial DC power supply
Operating Environment Temperature: -20℃ to +60℃
Storage Temperature: -40℃ to +85℃
Protection Grade: IP20 (installed in control cabinet)
Installation Method: S100 standard rack plug-in installation
Overall Size: 234mm × 324mm × 27mm
Net Weight: 0.372kg
Signal Response Time: ≤5ms
Relative Humidity: 5% to 95%, no condensation
Product Performance
The eight channels are independent of each other. A single-channel failure will not affect the normal output of the remaining channels.
Dual protection of software and hardware against overvoltage, overcurrent, and short circuit to prevent the board card from being burned out due to on-site line faults.
Support for long-distance analog signal transmission, with strong resistance to industrial electromagnetic interference.
Can be calibrated, range configured, and self-diagnosed for faults online.
Compatible with the backplane high-speed bus communication of the Advant system, with high real-time data transmission.
Support for parallel expansion of multiple modules in the rack, enabling large-scale expansion of analog control points.
IV. Application Domains
Thermal power, hydropower, new energy power plants: boiler dampers, fan frequency converters, water supply system process regulation
Petrochemical industry: reaction vessel regulating valves, raw material conveying pumps, pressure and flow closed-loop control
Metallurgical and steel industry: heating furnaces, rolling lines, dust removal system actuators for precise control
Paper industry: paper machine speed, drying cylinder temperature, pulp flow automatic regulation
Cement and building materials, water treatment industry: valve opening degree, drug pump frequency remote control
List of Similar Series Models
DSAI130: 8-channel analog input and acquisition module
DSAI140: 16-channel economical analog input module
DSDO110: 16-channel digital output module
DSDI110: 16-channel digital input module
DSAO120A: upgraded and optimized version of DSAO120 analog output module
DSBC172: S100 series bus communication interface module
