I. Product Description
This module belongs to the ABB Advant S100 DCS system and is a 4-channel relay-type digital output module. It realizes analog output through internal relay contacts and is used to drive on-site solenoid valves, indicator lights, alarms, small contactors, etc., to complete equipment start-stop, status indication, fault alarm, etc. control, and is a rack-mounted plug-in industrial spare part. It is mainly used for replacing spare parts in old DCS systems such as thermal power and chemical industries.
Key Technical Parameters
Channel quantity: 4 independent relay output channels
Contact type: Passive single-pole single-throw normally open contact
Contact rated capacity: AC 250V 5A, DC 30V 5A
Insulation withstand voltage: 1500VAC isolation between channels and backplane
Relay action response time: ≤10ms
Module power supply: Powered by the S100 system backplane
Operating environment temperature: -20℃ to +60℃
Storage temperature: -40℃ to +85℃
Operating relative humidity: 5% to 95%, no condensation
Protection level: IP20, limited to installation in control cabinets
Installation method: Standard S100 series rack plug-in installation
Module size: 234mm × 324mm × 27mm
Overall weight: 0.36kg
Equipped with hardware fault self-check and channel status diagnosis functions
Product Performance
The four channels are electrically isolated from each other, and a single-channel contact failure will not interfere with the operation of other channels.
The design of passive contacts is suitable for various on-site load power supply circuits of AC and DC, and the wiring is flexible.
Built-in over-voltage surge protection circuit can suppress reverse voltage shock generated by the on-off of inductive loads in the field.
Supports online diagnosis and can upload the relay engagement, disengagement, and channel fault status to the controller in real time.
Based on the high-speed backplane bus communication of the system, the timing of issuing switch instructions is strong, and the control response is stable.
Multiple modules can be stacked in the same rack for installation, and the on-site switch control points can be flexibly expanded.
IV. Application Fields
Thermal power plants: Electromagnetic valve drive for boilers and turbine systems, sound and light alarms, local indicator light control of equipment
Petrochemical industry: Valve start-stop of reaction devices, on-site alarm devices, pump interlock control output
Metallurgical industry: Start-stop interlock of heating furnaces and dust removal system equipment, fault sound and light alarm circuit control
Paper, cement, and building production lines: Conveyor equipment, auxiliary fans, on-site alarm signal output
Water treatment industry: Additive electromagnetic valve, sewage valve, high and low liquid level alarm contact control
List of Similar Model Numbers
DSDI110: 16-channel digital input module
DSDO110: 16-channel transistor digital output module
DSSR122: 4-channel relay isolation digital output module
DSAI130: 8-channel analog input module
DSAO120: 8-channel analog output module
DSBC172: S100 system bus communication module
