I. Product Description
ABB PP865A 3BSE042236R2 Panel 800 series 15-inch industrial human-machine interface touch screen, compatible with AC800M (800xA) DCS control system, serves as a local operation and monitoring terminal for the site, used for real-time monitoring of process parameters, manual operation of equipment, fault alarm query, trend curve viewing, process parameter setting and recipe management. It can communicate with the main control PLC, frequency converter, and third-party instruments via Ethernet, serial port, and can be installed in the control cabinet panel in an embedded manner. It is widely used in large-scale process industrial automation systems such as power, papermaking, metallurgy, and chemical industries, and belongs to common spare parts for industrial control.
Key Technical Parameters
Order Model: PP865A, Material Code: 3BSE042236R2
Screen Specifications: 15-inch TFT color LCD screen, resolution 1024×768, CCFL backlight, 262,000 colors
Touch Type: 4-wire resistive touch screen, supports glove operation, touch lifespan ≥ 1 million times
Hardware Storage: 64MB running memory, 32MB onboard flash memory, supports CF card program and data storage expansion
Power Supply Parameters: DC24V (20~30VDC), maximum power consumption of the entire machine 22W
Communication Interfaces: 1 10/100M shielded Ethernet, RS232, RS422/485, USB Host, USB Device,Profibus-DP expansion slot
Protection Grade： Front panel IP65， back panel terminal side IP20
Operating Environment： Vertical installation 0℃~+50℃， horizontal installation 0℃~+40℃； storage temperature - 20℃~+70℃； relative humidity 5%~85% without condensation
Installation Method： Embedded installation in the control cabinet panel， opening size 398mm×304mm
Overall Size： 398mm×304mm×66mm， net weight of the entire machine 3.7kg
Shell Material： Powder-coated aluminum alloy shell， panel with oil-resistant and corrosion-resistant film panel
Built-in Hardware： Battery-powered real-time clock， supports power-off time and alarm record storage
Electromagnetic Compatibility： Compliant with IEC61000 industrial anti-interference standards， with CE and UL safety certifications
Product Performance
Native deep compatibility with ABB AC800M series PLC, seamless integration with Control Builder configuration engineering, one-click adaptation of screens and variables, strong communication stability
Support for multi-level user permission encryption management, multi-language screen switching, real-time / historical alarm storage, trend curves, data report export functions
Compatible with Modbus TCP, Modbus RTU, Profibus-DP, ABB's own communication protocol, can be connected to frequency converters, tension meters, and third-party DCS devices
Support for USB program backup, screen download, production data export, without the need for an upper computer to complete on-site program update and data archiving
Equipped with backlight fault self-check and hardware watchdog abnormal automatic restart functions, suitable for factory 24-hour continuous operation conditions
Industrial-grade hardware design with wide temperature and voltage range, capable of withstanding dust, water mist, frequency converter electromagnetic interference, suitable for harsh industrial sites such as papermaking, metallurgy, and power plants
Support for multi-machine HMI networking to synchronize data, enabling multi-point collaborative monitoring and control in the central control room and local operation stations
Application Fields
Thermal power, hydropower, new energy power plants: boiler, turbine, auxiliary control system, excitation system local operation monitoring stations
Paper industry: paper machine, coating machine, rewinding machine drive, tension control system local operation terminals
Metallurgical industry: cold rolling, hot rolling, galvanizing, dust removal production line process parameter local monitoring and manual operation
Petrochemical industry: refining and chemical plants, compressors, reaction vessels, oil and gas transportation devices on-site human-machine operation panels
Water treatment, heat supply network, cement and building material production line centralized local automation monitoring
Battery, thin film materials, large packaging production line equipment operation status centralized monitoring and control
