I. Product Description
This module belongs to the ABB S800 I/O series and is compatible with the System 800xA DCS control system. It is a digital input interface expansion module, mainly used to collect on-site switch, limit, relay feedback, equipment start-stop status and other switch signals. After optical isolation, it is transmitted to the controller through the backplane bus to achieve on-site equipment status monitoring, interlock logic collection, etc. It is installed using DIN rail plug-in type, widely used for replacing spare parts of old control systems in process industries such as power, chemical, and metallurgy.
Key Technical Parameters
Ordering Model: LDGRB-01, Material Code: 3BSE013177R1
Signal Type: 24VDC Active Digital Input
Rated Power Supply: DC24V (18~32V), Total Power Consumption
Channel Electrical Isolation: Channel-to-ground 1500VDC Optical Isolation
Operating Environment Temperature: -25℃ to +70℃
Storage Temperature: -40℃ to +85℃
Relative Humidity: 5% to 95% RH, No Condensation
Protection Grade: IP20 (Only for Installation in Control Cabinet)
Installation Method: Standard 35mm DIN Rail Plug-in Type
Panel Configuration: Power Supply, Bus Communication, LED Status Indicators for Each Channel
Bus Type: S800 Standard Backplane Bus, Supports Hot Swap
Total Machine Net Weight: 0.32kg
Electromagnetic Compatibility: Complies with IEC61000 Industrial EMC Anti-interference Standards
Product Performance
Multi-channel independent optical isolation design can effectively suppress on-site ground loop interference and surge impact, protecting the main control system from being damaged by on-site faults
Supports self-check for channel breakage and short circuit faults, real-time uploading of abnormal states to the control system and panel indicator light alarms, facilitating quick maintenance
High-speed signal sampling can capture instantaneous switch transition signals, meeting the requirements for rapid signal collection of unit interlocks and protections
Multiple modules can be stacked in the same chassis for expansion, flexibly expanding the total number of switch quantity collection points in the entire plant, and multiple groups of S800 I/O stations can be hung on a single station
Seamlessly compatible with ABB Control Builder configuration software, supports online parameter configuration, channel forced, and signal online debugging
Wide temperature and voltage industrial-grade hardware design, capable of long-term stable and continuous operation in power plants, chemical plants, etc., with high dust and strong electromagnetic interference conditions
Application Domains
Fossil, hydropower, and gas-fired power plants: Boiler, turbine, auxiliary equipment start-stop feedback, valve limit, protection trip switch quantity collection
Petrochemical industry: Reaction equipment, compressor, pump-type equipment operation status, safety interlock switch signal collection and monitoring
Metallurgical and steel industry: Rolling line, blast furnace, dust removal fan, circulating water pump equipment local switch status centralized collection
Cement, paper production lines: Conveyor equipment, fans, valves, instrument fault alarm switch signal collection
Water treatment, urban heat pump station: Water pumps, electric valves, liquid level pressure switches and other on-site digital signals centralized monitoring
List of Similar Model Numbers
LDGRB-01: Standard Digital Input Module (This model)
LDGRB-02: High Channel Density Digital Input Expansion Module
LDGRB-03: Fault Redundancy Diagnostic Digital Input Module
LDOGR-01: S800 Series Relay-type Digital Output Module
CI801: S800 I/O Communication Interface Module
AI810: S800 Series Analog Input Acquisition Module
