Help CenterPt/ss4.16 Emergency Lighting Switch Driver Module, 4-channel Intelligent Lighting Controller for Scenic Areas
Related Products
-
Intelligent Street Light Power-saving Monitoring System, Voltage-stabilizing Energy-saving Lighting Controller Pgl-1250sd, Pgl-350sdUS$ 1538.46 - 1596.92MOQ: 1 Piece -
Remote Control Device for Factory Street Lights in Jinzhou, Energy-saving, Voltage-reducing and Flow-throttling, Aix-2c-100, Aix-2c-60US$ 1769.23 - 1815.38MOQ: 1 Piece
-
Thlxd-zm-50a, Thlxd-zm-120a Tunnel Lighting Energy Saver, Intelligent Street Lamp Voltage Regulation and Energy Saving DeviceUS$ 153.54 - 153.69MOQ: 1 Unit
-
Street Lamp Energy-saving Voltage Regulation Device, Remote Monitoring and Control Terminal System Shdy-bz-60, Shdy-bz-50US$ 152.31 - 153.69MOQ: 1 Piece
-
Voltage-stabilizing, Energy-saving, Regulation and Monitoring System Sl-3-80 Sl-3-150 National Road Street Light Energy Saver, Light Control With Longitude and LatitudeUS$ 1538.46 - 1596.92MOQ: 1 Piece
PT/SS4.16 Emergency Lighting Switch Driver Module, 4-channel Scenic Area Intelligent Lighting Controller can automatically collect various information in the lighting system according to environmental changes, objective requirements, user's pre - set requirements and other conditions, and conduct corresponding logical analysis, reasoning, judgment on the collected information, and store, display, transmit the analysis results in the required form, and perform corresponding feedback control of working state information to achieve the expected control effect. Zhejiang Juchuan Electrical Technology Co., Ltd. 0577-27877837, Quotation QQ421563834.
Technical Parameters:
Operating Voltage: 24VDC, 30MA
Communication Method: CAN Bus
Input Voltage: 220VAC
With 4-channel analog output and 4-channel relay output
Each channel's load output current is 16A, and the instantaneous current can reach 80A
Each channel's control signal output voltage is 1~10VDC, 20MA
Environmental Conditions: Operating Temperature 0℃－45℃
Protection Level: Three-proof can be customized
Installation and Use: Standard 35mm rail installation
PT/SS4.16 Emergency Lighting Switch Driver Module, 4-channel Scenic Area Intelligent Lighting Controller Performance Features:
① System integration. It is a modern control system integrating computer technology, computer network communication technology, automatic control technology, microelectronics technology, database technology and system integration technology.
② Intelligence. It is a control system with intelligent features such as information collection, transmission, logical analysis, intelligent analysis and reasoning, and feedback control.
③ Networking. Most of the traditional lighting control systems are independent, local and partial systems, which do not need to be connected through a dedicated network. However, the intelligent lighting control system can be a large-scale control system, which requires the support of computer network communication technology including hardware and software technologies for necessary control information exchange and communication.
④ Easy to use. Since various control information can be displayed in a graphical form, the control is convenient, the display is intuitive, and the lighting effect can be flexibly changed by programming.
Advantages of Intelligent Lighting Products:
Practical, safe and user-friendly functions
Simple and intelligent: The system is easy to use and can automatically adjust according to environmental changes.
Luxurious and comfortable: The operation panel has an attractive shape and color, and the system can create a charming atmosphere.
Practical and economical: The system functions are practical, and the integrated control greatly saves building energy.
Safe and reliable: The control circuit is completely separated from the load circuit. The working voltage of the control circuit is the safe voltage DC24V, which can ensure personal safety even if the switch panel leaks electricity accidentally.
Coordinated and flexible: The system can be arbitrarily combined and the functions can be changed according to user needs.
Open and compatible: It can be integrated with the building control system in various ways, and the system upgrade and maintenance are convenient.
Application Occasions: Public buildings and luxury villas
PT/SS4.16 Emergency Lighting Switch Driver Module, 4-channel Scenic Area Intelligent Lighting Controller.
