SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25

SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 thumbnail-1
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 thumbnail-2
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 thumbnail-3
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 thumbnail-4
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 thumbnail-5
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 photo-1
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 photo-2
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 photo-3
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 photo-4
SHANGHAI DONUN Electronic Pulse Spot Welding Machine JDM-3/5/10/16/25 photo-5
US$ 8000 1 Set
US$ 1500 ≥2 Set
Key Specifications
Get Latest Price
Type:
Universal
Style:
Fixed
Electric Current:
Capacitor Energy Storage
Contact Supplier Request Quote Chat Now
Shanghai Donsun Welding Group Technology Co.,Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Universal
Style Fixed
Electric Current Capacitor Energy Storage
Cooling Way Water Cooling
Electrode Stroke Vertical
Conductive Way Both-Sided
Welding Spot Number Multiple
Transmission Hydraulic
Control Automatic
Transport Package wooden case
Specification customize
Trademark donsun
Origin China

Electronic pulse spot welding machine

JDM-3/5/10/16/25



The JDM series electronic pulse spot welding machines adopt advanced

integrated circuits and thyristors to precisely control the heat and 􀆟me

of the main circuit. They are widely used in industries such as electrical

switches, instruments and meters, and metal products. These machines

can perform high - quality strong welding or brazing on low - carbon

steel, stainless steel, and non - ferrous metals.





  Model Unit JDM-3 JDM-5 JDM-10 JDM-16 JDM-25
Primary voltage V 1PH 220 1PH 220 1PH 380 1PH 380 1PH 380
 Rated capacity KVA 3 5 10 16 25
 Duty cycle % 20 20 20 20 20
 Throat depth mm 100 100 100 100 100
Throat gap mm 80 80 80 80 80
 Working stroke of   upper electrode mm 15 20 20 20 20
 Electrode pressure N 400 400 400 400 400
Welding thickness Low carbon steel mm 0.5+0.5 1+1 1.5+1.5 2+2 2.5+2.5
Stainless   steel mm 0.3+0.3 0.5+0.5 0.8+0.8 0.8+0.8 1.2+1.2
 Cooling water flow   rate L/min 1 1 2 2 2
Weight Kg 56 58 68 78 85
 Size mm 530×810×1050 530×810×1050 530×810×1050 530×810×1050 530×810×1050
