Shanghai Donsun Pneumatic Desktop Spot Welding Machine DN-16Q/25Q 12 DTM-20K-T

US$ 8000 1 Set

US$ 1500 ≥2 Set

Key Specifications

Type:

Universal

Style:

Fixed

Electric Current:

DC Shock Wave

Shanghai Donsun Welding Group Technology Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

7 days

Type Universal

Style Fixed

Electric Current DC Shock Wave

Cooling Way Water Cooling

Electrode Stroke Vertical

Conductive Way Both-Sided

Welding Spot Number Multiple

Transmission Hydraulic

Control Automatic

Transport Package wooden case

Specification customize

Trademark Donsun

Origin china

Pneumatic desktop spot welding machine

DN-16Q/25Q

DTM-20K-T

The desktop pneumatic spot welding machine is a welding

device that is driven by air pressure and mainly uses the

spot - welding process. Equipped with a desktop, it has a

compact structure and is easy to operate. It is often used for t

he welding and processing of small workpieces. It is mainly used to weld low - carbon

steel, stainless steel, galvanized sheets, etc., and can also weld non - ferrous metals

such as copper and aluminum. It is widely applied in fields such as electronics and

electrical appliances, hardware products, and daily - use products manufacturing.

Model		Unit	DN-25Q	DN-35Q	DN-50Q	DN-63Q
Primary voltage		V	1PH 380	1PH 380	1PH 380	1PH 380
Rated capacity		KVA	25	35	50	63
Rated Input current		A	66	94	132	166
Duty cycle		%	20	20	20	20
Secondary adjustment levels			Stepless	Stepless	Stepless	Stepless
Secondary coil No-load voltage		V	0.5-3.52	0.5-4.3	0.5-5	0.5-6.7
Throat depth		mm	350	350	350	350
Throat gap		mm	220	220	220	220
Working stroke of upper electrode		mm	60	60	60	60
Electrode pressure		N	4000	4000	4000	4000
Electrode size	Electrode arm	mm	φ55	φ55	φ55	φ55
Electrode size	Electrode holder	mm	φ25	φ25	φ25	φ25
Welding thickness	Low carbon steel	mm	2+2	2.5+2.5	3+3	3.5+3.5
Welding thickness	Stainless steel	mm	0.8+0.8	0.9+0.9	1+1	1.2+1.2
Compressed air pressure		Mpr	0.6	0.6	0.6	0.6
Cooling water flow rate		L/min	6	6	6	6
Recommended input wire cross - section		mm²	8	16	16	16
Weight		Kg	250	260	280	300
Size		mm	940×520×1450	940×520×1450	940×520×1450	940×520×1450
