Simple Polarizing Microscope MP20
US$ 1
≥1 Set
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2003
Overseas Office:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Routine Biological Microscope With Trinocular Observation Tube ML31US$ 500 - 2000MOQ: 1 Set -
Inverted Biological Microscope With Phase Contrast MI52-NUS$ 500 - 2000MOQ: 1 Set
-
Scientific Grade Metallurgical Microscope MJ43US$ 500 - 2000MOQ: 1 Set
-
Professional Polarizing Microscope MP41US$ 500 - 2000MOQ: 1 Set
-
Research-grade Inverted Biological Microscope MIX60US$ 1MOQ: 1 Set
Description
Feature
Specification
MP20 Polarizing Microscope is a kind of essential instrument for studying and identifying the materials with double refraction characteristics, by using polarizing feature. This microscope is widely used in many fields, such as observation of crystalline inclusions, muscle tissue, nerve tissue, plant fiber and other structural details of the teeth, bone, and living cells, as well as analysis of drug composition and properties. Furthermore, in the field of inorganic chemistry, the fine structure of crystallization conditions of various kinds of salts which cannot be seen in natural light can be observation through polarizing microscope.
Feature
Clear image:
Equipped with wide-field eyepieces and achromatic objectives, the field of view is large and clear.
Coarse and fine focusing, limit locking:
Coaxial coarse and fine motion focusing mechanism, adjustable coarse and tight motion, with limit locking device.
Halogen transillumination, adjustable brightness:
Halogen lamp transmitted lighting, brightness adjustable.
Specification
| Items | Specification |
| Eyepiece | Wide field WF10X(Φ18mm) |
| Objective | Achromatic objective 4X/0.10 |
| Achromatic objective 10X/0.25 | |
| Achromatic objective 40X/0.65 (Spring) | |
| Achromatic objective 100X/1.25(Spring, oil) | |
| Observation tube | Binocular, inclined 30° |
| Analyzer | Sliding |
| Focus system | Coaxial coarse/fine focus system, with tension adjustable and limit stopper,minimum graduation in fine movement is 2μm |
| Nosepiece | Quadruple (Backward ball bearing inner locating) |
| Stage | Rotatable stage (Diameter:Φ120mm) |
| Abbe condenser | NA.1.25 Rack & pinion vertical adjustable |
| Filter | Blue filter |
| Frosted glass | |
| Polarizer | 360° rotatable |
| Analyzer | Push-pull |
| Illumination unit | 6V 20w, halogen bulb, brightness adjustable |
