Home > Products > Routine microscope > Scientific grade metallurgical microscope MJ43
Scientific grade metallurgical microscope MJ43
- 500 Set / Sets per Month
- HUANGPU
- T/T PayPal
- 7 days
Product Details
Brand Name: | MSHOT | Place of Origin: | China | Model Number: | MJ43 |
Theory: | Metallurgical Microscope | Drawtube: | Trinocular |
Product Description
MJ43 is a research level metallurgical microscope with reflected lighting and transmitted lighting. Multi-function lighting attachment and broad-spectrum LED light source allows the microscope expand to reflected fluorescence function. The microscope body and structure is equivalent to Olympus BX43 optimized optical performance, offering various observation method possibility of dark field and DIC. All features give the microscope system ability to achieve composite micro observation of semi-conductor, FPD, electronic board, precision metal parts, physical materials and related industry area. It’s an ideal instrument for university laboratory, education and scientific research purpose.
Features:
Equivalent quality of Olympus BX43 microscope body.
Flexible expand to observation method of epi-fluorescence, dark field and DIC.
Broad-spectrum LED light source is high efficiency and environment friendly.
Semi-apochromatic metallurgical objectives are clear and bright to view metal and no coverglass specimen.
Turret accommodates maximum sextuple filter block cubes allows to add filter cubes by needs.
Transparent plate is convenience to hold powder specimen.
Specification:
Microscope frame | Optical system | Universal Infinity-corrected optical system |
Structure | Original from international famous brand microscope | |
Observation | Hinged type trinocular observation tube with 30°inclination | |
Wide field eyepiece 10X/22mm, high eye-point, interpupillary distance 53~75mm | ||
Nosepiece | Quintuple nosepiece | |
Objectives | Semi-apochromatic metallurgical objective PlanFluor EPI 5X/0.15,WD:20mm | |
Semi-apochromatic metallurgical objective PlanFluor EPI 10X/0.3,WD:11mm | ||
Semi-apochromatic metallurgical objective PlanFluor EPI 20X/0.45,WD:3mm | ||
Semi-apochromatic metallurgical objective PlanFluor EPI 50X/0.8,WD:1mm | ||
Optional objectives | Bright field & dark field metallurgical objective N-MPFN 5X/0.15 BD,WD:20mm | |
Bright field & dark field metallurgical objective N-MPFN 10X/0.3 BD,WD:11mm | ||
Bright field & dark field metallurgical objective N-MPFN 50X/0.8 BD,WD:1mm | ||
Bright field & dark field metallurgical objective N-MPFN 100X/0.9 BD,WD:1mm | ||
Stage | Coaxial stage with left or right hand low drive control: with rotating mechanism and torque adjustment mechanism | |
Travel distance 80mm×50mm, 1mm per scale, accuracy 0.1mm | ||
Triple-layer mechanical stage with glass plate clamp | ||
Transparent glass plate 97mm×76mm | ||
Reflected illumination | Turret accommodates maximum sextuple filter block cubes | |
Mirror units of bright field | ||
Digital control LED light control box, AC110V/220V | ||
30W board-spectrum LED light source MG30 | ||
Connector of broad-spectrum LED light source | ||
Analyzer and polarizer | ||
Optional illuminating system | 12V100W halogen lamp house and control box | |
Focus | 25 mm stage stroke with coarse adjustment limit stopper, torque adjustment for coarse adjustment | |
knobs, stage mounting position variable, minimum adjustment gradations: 1 µm | ||
Transmitted illumination system | Warm white LED lamp, brightness is continuously adjustable | |
Abbe condenser, N.A. 1.1 | ||
Power line | According to user's country electrical requirement | |
Screw driver | M3.0 hexagon screw driver | |
Accessories | Immersion oil | |
Dust cover | MSHOT special dust cover | |
Optional adapters | 1X/0.5X/0.75X C-mount adapter |
