Polarization microscope MP41 is a professional microscope equipped with polarizing device, reflective lighting and transmitted lighting. It is favorable for studying and identifying the materials which has double refraction characteristics, by using the feature of polarizing. Users can use it to do observation of mono-polarization, orthogonal polarization and conoscopic observation. It is widely used in geology, chemistry and pharmaceutics, as well as observation of liquid polymer materials, biopolymers and crystalline phase of the liquid crystal material. This microscope is an ideal laboratory instrument for institutions and universities to conduct research and teaching.
100% light pass for photography capable
Graduated 0.10mm/Div eyepiece, field of view 22mm
Strain-free plan achromatic objective
Rotatable 360° polarizer and analyzer
Both epi illumination and transmitted illumination with polarizer and analyzer
With λ ,λ/4 and quarts wedge compensator
Pull type Bertrand lens and center adjustable
With blue filter and frosted glass
Geology department research
Material of medicine research
Crystal featured objects
Liquid polymer materials
Specificaton:
| Model | MP41 |
| Observation tube | Trinocular, inclined 30°, 100% light pass for photography capable |
| Eyepiece | Wide field WF10X(Φ22mm) |
| Graduated WF10X(Φ22mm) 0.10mm/Div | |
| Objective | Strain-free plan achromatic objective (no cover glass) |
| PL L5X/0.12 (Work distance):26.1 mm | |
| PL L10X/0.25 (Work distance):20.2 mm | |
| PL L40X/0.60(spring) (Work distance):3.98 mm | |
| PL L60X/0.70(spring) (Work distance):3.18 mm | |
| Reflective illuminating system | 6V30W halogen, brightness adjustable. |
| Polarizer can be rotated 360°. | |
| Analyzer can be rotatable 360° with scale and minimum vernier | |
| Integrated field diaphragm and aperture diaphragm | |
| Nosepiece | Quadruple (center adjustable ) |
| Intermediate attachments | Pull type Bertrand lens and center adjustable |
| Compensator | λ ,λ/4 and quarts wedge compensator |
| Focus system | Coaxial coarse/fine focus system, with tension adjustable and limit stopper, Minimum graduation in fine movement: 2μm |
| Transmitted illuminating system | 6V30W halogen, brightness adjustable, lamp center adjustable |
| Abbey condenser,liftable,NA 1.25 | |
| Blue filter | |
| Frosted glass | |
| Polarizer (360° rotatable with 0°,90°,180°,270° division) | |
| Camera adapter | 1X C-mount adapter |
