MSHOT ML31 biological microscope received positive feeback from medical and educational area, it offers superior optical performance with excellent cost-effciency. Plan achromatic objectives are flat and clear in view, bring microscope users high contrast and sharpness image. Wide field of view eyepiece is high efficiency for microscopy work. The illumination employs cold LED light has high bright and stable lighting. Rigid and durable construction makes the microscope maintains high performance even after long time using. More with 0.5X C-mount adapter for user to connect digital camera freely, mostly reproduce equal image in eyepiece.
Infinity Corrected achromatic optical system
Infinity plan achromatic objectives
Eyepiece filed of view 22mm, diopter adjustable
Head with 100% light for eyepiece or camera.
0.5X C-mount adapter for big field of view close to eyepiece view.
LED lamp color temperature around 4300K
Stage slider holder can hold double pieces slide at one time.
Can expand to polarizing and fluorescence function.
Applications:
Biology slides
Blood, sperm, TCT, IHC, tissue
Pathology
Education
Medicine material
Plant
| Optical system | Infinity Corrected Achromatic optical system | |
| Observation tube | Hinged Trinocular tube, 30° inclined, interpupillary distance 53mm-75mm | |
| Eyepiece | Wide field plan eyepiece WF10X / FN22mm , high eyepoint | |
| Optional eyepiece | Wide field plan eyepiece WF16X/ F.N.15mm | |
| Nosepiece | Quadruple nosepiece with inward tilt | |
| Objective | Infinity plan achromat objectives | |
| 4X, NA0.1, working distance 21.5mm | ||
| 10X, NA0.25, working distance 7.5mm | ||
| 40X, NA0.60, working distance 0.65mm | ||
| 100X(oil), NA1.25, working distance 0.185mm | ||
| Optional objectives | Plan achromat 20X, NA0.40 | |
| Condenser | Abbe condenser NA1.25 | |
| Focus | Coaxial coarse and fine adjustment with limit stopper and lock device | |
| Stage height movement (coarse movement stroke: 24mm) | ||
| Stroke per rotation: 40mm | ||
| Microstroke per rotation: 0.2mm | ||
| Stage | Double-deck mechanical stage, size 210×140mm, moving range 76mm×50mm slider holder can hold double pieces slides at one time | |
| Transmitted light | White LED, brightness adjustable | |
| Power line | International standard | |
| Adapter | 1X C-mount adapter | |
| Optional adapter | 0.5X C-mount adapter | |
Optional Accessories
| Eyepiece | Wide field plan eyepiece WF16X/ F.N.15mm(optional) |
| Objective | Plan achromat 20X, NA0.40 |
| Plan achromat non-cover glass objective 20X, 40X | |
| Semi plan achromat 4X,10X,20X,40X,100X | |
| Fluorescence objective 4X,10X,20X,40X,100X | |
| Polarization | Simple polarizer plate and analyzer plate |
| LED Epi-Fluorescence illumination | MF-B-LED / MF-RB-LED/MF-UV-LED/MF-G-LED |
| blue Ex 460~490nm/royal blue Ex 420~480nm/UV Ex330~380nm/Green Ex 510~550nm | |
| MF-BG-LED /MF-BU-LED | |
| MF-BGU-LED blue, green and UV excitation | |
| Heating stage | TP R200-M surrounding temperature ~ 50℃, 165x113cm |
