35 Degree Slant Bed TX500EY Cnc Lathe Turning Machine Milling Cnc Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Desktop CNC Lathe Machine CNC210 With Siemens808D For Hobby School And TrainingNegotiableMOQ: 1 -
Cnc Lathe Manufacturers CK6166x3000 Machine Cnc Lathe Cnc Lathe Machine With Fanuc ControlNegotiableMOQ: 1
-
Lathe Machine CK6150 X750 Length Lathe Machining Torno CNC for Threads MakingNegotiableMOQ: 1
-
CAK6166 CNC Lathe Machine for Making ThreadsNegotiableMOQ: 1
-
CK6180 High Quality CNC Lathe MachineNegotiableMOQ: 1
Product Description
35 degree slant bed cnc lathe turning center TX500EY
Main Features:
1. Able to flexibly handle various workpieces.
2. The 12-station power turret enables the operator to machine simple to complex workpieces with one easy setup operation.
3. These models also feature a Direct Drive Spindle ( Integrated Motor) that reaches high speed while maintaining strict rigidity and exceptional C-Axis accuracy.
4. WMTCNC Turning center have a heavy-duty cast base with "True Align" bed design. 5. This design feature reduces heat build-up and resulting thermal expansion.
6. Cylindrical type guideways and large diameter high precision ballscrew provides improved rigidity and higher accuracy. 7. With a very low coefficient of friction, they consume less power and do not require adjustment.
Specification |
Unit |
TX500EY |
||||
Capacity |
Max. turning diameter |
mm |
320 |
|||
Max. length of workpiece |
mm |
650,*1000,*1500 |
||||
Max. swing dia. over bed |
mm |
600 |
||||
Max. swing dia. over slide |
mm |
430 |
||||
Spindle |
Hydraulic chuck/Collet chuck |
Inch |
8 |
|||
Spindle bore |
mm |
Ø66 |
||||
Max. dia. of through-hole |
mm |
Ø52 |
||||
Spindle nose |
type |
A2-6 |
||||
Spindle speed |
rpm |
4000 |
||||
Main motor power |
kW |
22/30 |
||||
Axis |
X axis travel |
mm |
250 |
|||
Z axis travel |
mm |
650,*1000,*1500 |
||||
Y axis travel |
mm |
100(+-50),*140(+-70) |
||||
X/Z/Y axis rapid traverse |
m/min |
20/20/12 |
||||
Turret |
Type of turret |
BMT45,*BMT55 |
||||
No. of tool |
12 |
|||||
OD tool shank size |
mm |
20X20,*25X25 |
||||
Boring tool shank size |
mm |
Ø32 |
||||
Max. speed of live tooling |
rpm |
4000,*6000 |
||||
Tailstock |
Type of tailstock |
SPT,*SST |
||||
Taper of tailstock quill |
MT3(spindle unit type) |
|||||
Travel of tailstock |
mm |
100-650 |
||||
Structure |
Slant bed degree |
degree |
35 |
|||
Guideway type |
mm |
LM |
||||
Others |
Overall dimension (LxWxH) |
mm |
3000X1780X2050 |
|||
Weight (about) |
kg |
4800 |
||||
Note: "*"means optional, "LM" means linear guideway. |
||||||
Detailed Images
Company Profile
Professional Service
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4: What’s the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes, we have professional engineers and designers. We can provide OEM services.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
