8-station Turret Linear Guideway SWL600/750 Cnc Slant Bed Turning Center With CE Certificate

Jingjiang Fuji Technology Co., Ltd.
4Yrs
8-station Turret Linear Guideway SWL600/750 Cnc Slant Bed Turning Center With CE Certificate thumbnail-1
8-station Turret Linear Guideway SWL600/750 Cnc Slant Bed Turning Center With CE Certificate thumbnail-2
8-station Turret Linear Guideway SWL600/750 Cnc Slant Bed Turning Center With CE Certificate photo-1
8-station Turret Linear Guideway SWL600/750 Cnc Slant Bed Turning Center With CE Certificate photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Description
Main Features:
1. The SWL Series high-performance turning centers were designed from to provide setup flexibility, superb rigidity, and excellent thermal stability.
2. These machines offer high cost performance.
3. SWL lathe have a heavy-duty cast base with “true align” slant bed design.
4. The machine bed, headstock, turret and tailstock are aligned on the same plane.
5. This unique design feature reduces heat built-up and resulting thermal expansion.
6. The net result is higher precision machine tool.
7. Additional resulting efficiencies from the “true align” design are greater rigidity and smoother operation which provides a variety of benefits.
8. You can expect to produce highly accurate parts with extremely fine surface finishes.
9. It extremely minimizes the impact of thermal expansion to precision.
10. 35 degree slant bed is more convenient for scrap iron.
11. Better dynamics and higher precisions.
12. It realizes an optimized combination of high-precision, high bearing capacity, good running speed and it is more durable.
13. Increasing the versatility and automation of the lathe.
14. Better water-resistant and scrap-iron-resistant.
Specification
Unit
SWL600/750
Capacity
Chuck size
inch
8",*10"
Max. swing dia. over bed
mm
Ø600
Max. length of workpiece
mm
750
Max. swing dia. over slide
mm
Ø360
Spindle
Spindle bore
mm
Ø62
*Ø75
Max. dia. of through-hole
mm
Ø52
*Ø65
Spindle nose
type
A2-6
*A2-8
Spindle speed
rpm
4000
*1600
*2000
*3500
Main motor power
kW
7.5/11,*11/15
Axis
X axis travel
mm
260
Z axis travel
mm
750
X/Z rapid traverse
m/min
20/20
Turret
Center height
mm
100
No. of tool stations
nos
8,*12
Tool shank size
mm
25X25
Tailstock
Type of tailstock
SST,*HPT
Taper of tailstock quill
MT3
Travel of tailstock quill
mm
0
Travel of tailstock
mm
100-750
Structure
Slant bed degree
35
Guideway type
LM
Others
Power capacity
kVA
16
Overall dimension (LxWxH)
mm
3080X2000X2350
Weight (about)
kg
5200
Detailed Images
Company Profile
Professional Service
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.

Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4: What’s the MOQ?
A4: One set only.

Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6: Do you have professional engineers?
A6: Yes.we have professional engineers and designers. We can provide OEM services.

Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
