Description
The cell imager MCS11/MCS21/MCS22 live cell imaging monitoring system greatly simplifies your workflow.
Through automated timed observation, analysis and reporting, you can remotely monitor the cell culture progress without entering the clean room or opening the incubator, greatly improving work efficiency and avoiding the risk of interfering with growth and contaminating samples.
Intelligent functions:
Intelligent live cell imaging monitoring system greatly simplifies your workflow. Through automated timed observation, analysis and reporting, you can remotely monitor the progress of cell culture without entering the clean room or opening the incubator, thereby improving work efficiency and reducing interference and contamination risks.
Fluorescence standard version MCS21/22:
It has bright field, phase contrast and fluorescence imaging, and comes standard with two blue and green fluorescence channels, suitable for monitoring cell transfection and cell activity, etc.
The bright field basic version MCS11:
625nm red LED light source phase contrast observation can reduce cell photobleaching and is suitable for cell observation, confluence analysis, scratch healing and other scenarios.
Feature
Intelligent functions
Fluorescence standard version
The bright field basic version MCS11
Specification
| Item | Specification |
| Item No. | Live cell imager MCS11/MCS21/MCS2 |
| Bright field imaging | Transmitted phase contrast illumination, working distance 70mm |
| Long life low phototoxicity LED light source：625nm | |
| Fluorescence observation | MCS11: None MCS21/MCS2: Blue (B)：475/30nm MCS21/MCS2: Green (G)：560/40nm MCS21/MCS2: Three-color fluorescence optional, band customizable |
| Objective | MCS11:Single objective lens: 4X/10X/20X objective lens optional MCS21:Single objective lens: 4X/10X/20X objective lens optional MCS2:Dual objective lens: Electric switching MCS2:4X/10X/20X objective lens optional |
| Platform | Flat stage, manual movement |
| Body size | MCS11: W*L*H：143mm*232mm*182mm MCS21/MCS22: W*L*H：214mm*260mm*182mm |
| Z-axis | Electric focus, automatic focus |
| Camera | MCS11: 5 megapixel bright field camera MCS21/MCS22:High-speed and high-sensitivity fluorescence camera 5 megapixels; chip size: 2/3 inch; frame rate: 40fps |
| Software | Adopt C/S architecture, support remote control, including lighting control, camera control, photo taking, video recording, time-lapse photography, cell counting, cell confluence, scratch test; external network control, email reminder |
| Data transmission/power supply | USB data cable + DC power supply cable |
| Work Environment | 5-42˚C, 5-95%RH |
