UTM-300AC Computer-control Automatic Universal Testing Machine
Charateristic
a. It can do tensile, compression, bending and shear test for all kinds of metal materials and nonmetal materials such as plastic, concrete, cement and so on.
b. The machine is electric underlying oil cylinder, computer control, electro-hydraulic servo.
c. The machine has the specification of high precsion, easy operation, large capacity for data store and curve displaying.
d. These frames features are dual spaces, so users can quickly change between tensile and compression testing without having to remove heavy fixtures.
| Model | UTM-100AC | UTM-300AC | UTM-600AC | UTM-1000AC | |||
| Capacity | 100KN | 300KN | 600KN | 1000KN | |||
| Accuracy | ±1% | ±1% | ±1% | ±1% | |||
Power supply |
220V, 50Hz/380V | 220V, 50Hz/380V | 220V, 50Hz/380V | 220V, 50Hz/380V | |||
Tensile space |
550mm | 550mm | 640mm | 700mm | |||
Thickness of flat specimens |
0-12mm | 0-15mm | 0-30mm | 0-40mm | |||
| Diameter of round specimens | Φ6-20mm | Φ10-32mm | Φ12-40mm | Φ20-60mm | |||
Power |
1500W | 1500W | 1500W | 1500W | |||
| Overall dimensions (frame) | 640x550x1800mm | 900x600x2200mm | 1060x760x2400mm | ||||
Our products are 100% supplied from the factory
If you are interested in our products, you can contact us directly or welcome to visit our site:
SKYPE ID: sun.nancy3
