NDW-10 Computer Control Medical Bone Screw Torsion Testing Machine
Charateristic
a.The Torsion Testing Machine applicable to medical bone screw and some similar materials, and ferrous,non-ferrous, composite materials and structural components for torsion test.
Our products are 100% supplied from the factory
If you are interested in our products, you can contact us directly or welcome to visit our site:
SKYPE ID: sun.nancy3
Computer Control Medical Bone Screw Torsion Testing Machin
| Model | NDW-10 | NDW-20 | NDW-50 |
Max. torque | 10Nm | 20Nm | 50Nm |
Measuring range of torque | 1-10Nm | 1-20Nm | 1-50Nm |
Relative error of indicating value of torque | ±1% | ||
Relative error of repeatability of indicating value of torque | ≤1% from each range | ||
Measuring range of torsion angle | 0.01°-9999.9° | ||
Min. Resolution of torsion angle | 0.1° | ||
Relative error of angle | ≤±1% | ||
Min. resolution of angle | 0.1° | ||
Max.distance of two chucks | 200mm | ||
Torsion speed | torsion speed | ||
| Rotation direction | bi-direction | ||
Specimen size | as required | ||
Power supply | 220V±10%,50Hz | ||
Motor power | 0.4kW | ||
Dimension of loading frame |
675×360×430mm
| ||
