RDW Computer Control Electronic Creep Stress Rupture Testing Machine
Charateristic
a. Applicable to creep property and stress-rupture strength test for metals and alloys at room temperature and high temperature, is special testing equipment in ferrous metallurgy, aerospace aviation,scientific institute,colleges and quality supervision,etc.
Our products are 100% supplied from the factory
If you are interested in our products, you can contact us directly or welcome to visit our site:
SKYPE ID: sun.nancy3
Computer Control Electronic Creep Stress Rupture Testing Machine
Measuring range of load |
500N~50kN/1KN~100kN |
Accuracy of load |
Better than ±1% |
Load resolution |
1/300000 |
Max.loading rate |
3000N/s |
Load control stability |
Better than±1% |
Moving speed |
0.001~100mm/min |
Error of moving speed |
±1% |
Stroke of pull rod |
200mm |
Eccentricity of upper and lower pull rod |
≤8% |
Counting error |
±0.1% |
Power supply |
220V±10% |
Servo motor power |
0.85kW |
| Stable working time | More than 1000hrs. |
Dimension (L*W*H) |
810*760*2550mm |
Working temperature range |
Room temperature-1000℃ |
Temperature control accuracy of furnace |
±2℃ |
Dimension of control cabinet (L*W*H) |
600*600*1600mm |
Dimension of main machine (L*W) |
3500*3000mm
|
