Microcomputer Static Load Anchorage Testing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Geotest Equipments
Model Number:
ATM-6500
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai or other port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RDW Computer Control Electronic Creep Stress Rupture Testing MachineNegotiableMOQ: 1 Set -
UTM-B Automatic Servo Hydraulic Universal Test MachineNegotiableMOQ: 1 Set
-
CTM-2000 Digital Display Compression Testing Equipment CTM, Pressure Testing MachineNegotiableMOQ: 1 Set
-
CTM-2000B Computer-controlled Automatic Compression Testing MachineNegotiableMOQ: 1 Set
-
WDT-30 Welding Machine Drop and Lifting Testing MachineNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Geotest Equipments
Model Number
ATM-6500
Power
Electronic
Usage
Other, Computer-controlled Static-load Anchor Testing Machine
ATM-6500 Microcomputer Static Load Anchorage Testing Machine
Characteristics:
a. Used for static-loading anchor testing for steel strand wires both of single-strand and multi-strand samples in sizes of Φ21.8mm, Φ17.8mm and Φ15.24mm.
b. It can detect both single-pore and multi-pore anchorage.
c. Adopting load sensor to measure load, controlled and displayed by computer, with high control precision.
d. With maintenance functions of max. load peak and displacement peck.
e. With overload protection function.
Our products are 100% supplied from the factory
If you are interested in our products, you can contact us directly or welcome to visit our site:
SKYPE ID: sun.nancy3
| Loading capacity | 6500KN | |||
| Measuring range | 4%-1000% | |||
| Force accuracy | ±1% | |||
| Control rate of testing force | 1KN/s-50KN/s | |||
| Speed range | ≤±5% |
|||
| Measuring range of displacement | 0-200mm | |||
| Displacement accuracy | ±1% | |||
| Repeatability | ±0.5% | |||
| Relative resolution | ±0.5% | |||
| Piston stroke | 200mm | |||
| Tensile space | 3400mm | |||
| Main frame dimensions | 5030x700x2060mm | |||
| Control cabinet dimensions | 1180x800x1310mm | |||
| Power supply | 380V | |||
| Total power | 3.5KW | |||
| Weight approx | 4000kg | |||
