ITM-300 Charpy Test Machine / Charpy Impact Test Machine /impact Tester Price
Specifications
Dial,Digital,PC controlled;Manual or automatic sample feeding;
ITM-300 Impact Testing Machine
Characteristic:
Used in determine the impact resistance capacity under dynamic load.
| Model | ITM-300 |
| Impact energy | 150J,300J |
| Pendulum elevation angle | 150° |
| Span of specimen supports | 40mm |
| Jaw fillet | R1-1.5mm |
| Impact blade angle | 30°±1° |
| Impact blade thickness | 16mm |
| Specimen specification(standard) | 10x10x55mm |
| Impact speed | 5.2m/s |
| Arc radium of impact blade | 2-2.5mm |
| Bearing elevation angle of specimen support | 0° |
| Power supply | 3 phase,4 wire 380V,50Hz,180W(main motor) |
| Weight approx | 450kg |
