Digital Concrete Compression Testing Machine
1. Characteristic
a. Compression testing of concrete cubes and cylinders
b. Cushion type, easy to operate.
c. New design.
d. The load frame is of high quality steel construction.
e. Good and stable performance.
2. Function
a. This compression testing machine is suitable for doing compressive strength test the building materials such as brick, cement mortar, and concrete and so on.
b. This compression testing machine is also suitable for the mechanical properties test for other materials.
c. This compression testing machine has loading pressure in digital display, Max. loading pressure maintenance, power-off data protection and so on.
d. This compression testing machine can automatically process the test data and automatically print out the test
report.
Digital Concrete Compression Testing Machine
Loading capacity | 2000KN |
Measuring range | 0-2000KN |
Relative indication error | ±1% |
Size of bearing platen | Φ260mm |
Max. distance between upper and lower platen | 340mm |
Max. ram stroke | 50mm |
Diameter of ram | Φ270mm |
Rated pressure of the hydraulic pump | 35Mpa |
Power | 220V 50HZ |
Outside size | 960*480*1285mm |
Net weight | About 700kgs |
Digital Concrete Compression Testing Machine
The biggest manufactor is in china, the top quality is in china, the best service is also in china!
Pls believe GEOTEST, Believe China Power!
We sincerely lookinf forward to cooperate with you!
