Home > Instruments & Meters > Test Instrument > Test Machine > FTM-1000 Flexural and Compressive Test Machine Manufacturer (Computer-controlled Electro-hydraulic Servo)
FTM-1000 Flexural and Compressive Test Machine Manufacturer (Computer-controlled Electro-hydraulic Servo)
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Geotest Equipments
Model Number:
FTM-1000
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UTM-100B Universal Testing Machine Price, Automatic Compression Tensile Tester,Peel Strength Testing MachineNegotiableMOQ: 1 Set -
CTM-2000 Digital Concrete Compression Testing MachineNegotiableMOQ: 1 Set
-
Concrete Compression TesterNegotiableMOQ: 1 Set
-
2017 New Type Universal Testing Euipment AutomaticalNegotiableMOQ: 1 Set
-
NDW-10 Computer Control Medical Bone Screw Torsion Testing MachineNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Geotest Equipments
Model Number
FTM-1000
Power
Electronic
Usage
Universal Testing Machine
Compression & Flexure Testing Machine
(Computer-controlled Electro-hydraulic Servo)
Functions:
Used for compression and flexural tests on concrete samples.
| Capacity | 10-1000KN | |||||
| Accuracy | ±1% | |||||
| Compression space | 0-100mm (adjustable) | |||||
| Upper platen size | 300mm dia. | |||||
| Lower platen size | 400x300mm | |||||
| Span between columns | 500mm | |||||
| Ram trave | 0-150mm | |||||
| Loading speed | 0-40KN/s (adjustable) | |||||
| Power supply | 3 ph., 4-wire, 380V, 50Hz, 1500W | |||||
| Overall dimensions | 600x540x1500mm (frame) 1080x600x960mm (control cabinet) | |||||
| Weight approx | 1000kg | |||||
