TTM-500 Computer-controled Electrical Torsion Testing Machine
Charateristic
a. The machine is used to determine static mechanical properties for metallic, non-metallic and other component such as transmission shaft, half shaft, etc.
Our products are 100% supplied from the factory
If you are interested in our products, you can contact us directly or welcome to visit our site:
SKYPE ID: sun.nancy3
| Model | TTM-50/100/200 | TTM-500/1000 | TTM-2000 | TTM-3000 |
| Capacity | 50/100/200 Nm | 500/1000 Nm | 2000 Nm | 3000 Nm |
| Class | Class 1 | |||
| Range | 2%-100%F.S | |||
| Accuracy | ± 1% | |||
| Repeatability | ≤1% | |||
| Torsion angle range | 0-9999° | |||
| Torsion angle resolution | 0.01° | |||
| Max.distance between the clamping heads | 300 mm | 600 mm | 650 mm | 200-1000 mm adjustable |
| Central height of main shart | 100 mm | 170 mm | 200 mm | ≥120 mm |
| Torsion direction | Bidirectional Torsion | |||
| Sample size | Φ8- Φ10 | Φ8- Φ20 | Φ8- Φ28 | As required |
| Power supply | 220V,50HZ | |||
| Motor power | 0.4 KW | 0.75 KW | 0.85 KW | 3 KW |
