Home > Instruments & Meters > Test Instrument > Test Machine > Concrete Compression Tester

Concrete Compression Tester

Name: Concrete Compression Tester
Brand: GEOTEST EQUIPMENT, GEOTEST EQUIPMENTS
SKU: 143208002
Availability: InStock

Shaoxing GeoTest Equipment Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

GEOTEST EQUIPMENT, GEOTEST EQUIPMENTS

Model Number:

CTM-2000B/3000B

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai Negotiable

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name GEOTEST EQUIPMENT, GEOTEST EQUIPMENTS

Model Number CTM-2000B/3000B

Power Electronic

Usage Other, Compression Testing Machine, Compression Testing Machine

Concrete Compression Tester

GB/T50081-2002,GB/T2542-2012

Features:

1.The Tensile Compression Tester using frame

structure,has screw lifting structure, fuel tanks mounted under design,the lift motor can drive the screw to adjust the test space.

2.The Tensile Compression Tester using the latest

technology of servo pump control Loading system,low noise, fast response, and stable.

3.Screw down automatically when the test begin and up automatically when the test finished ,which ensure the test to be finished efficiently.

4.10-inch touch panel PC man-machine interface, combined with the Independently developed

embedded control software, structure is compact and convenient for operation.

5.During the test the computer can automatically display the load, strength, speed and load curves, automatically determine the sample broken,calculate and save the test results, can query and print the complete test report.

Tensile Compression Tester

Model	CTM-2000B	CTM-3000B
Max.load(kN)	2000	3000
Measuring range(kN)	200kN-2000kN	300kN-3000kN
Loading measuring accuracy	≤±1%
Upper Platen size(mm)	250×220	330×320
Under Platen size(mm)	250×220	330×320
Max.distance between upper and lower pressure plate(mm)(mm)	370	370
Max.Piston stroke (mm)	60	80
Effective column distance (mm)	390	490
Power(kW)	1.8
Input Voltage	AC220V ±10%
Overall dimensions(mm)	980 × 440 ×1350	1180 × 480 × 1500
Approx Weight(kg)	1350	2200
