Help Center304 Stainless Steel Skid-Mounted Evaporator With PLC Control for Industrial Wastewater Treatment
Product Spotlights
Related Products
-
Skid-Mounted Evaporator for Zero Liquid Discharge in Oil & Gas Field Brine ConcentrationUS$ 32600 - 875000MOQ: 1 Combo -
PLC Controlled Skid-Mounted Evaporator 380V 3-Phase 50Hz With Touch Screen InterfaceUS$ 32600 - 875000MOQ: 1 Combo
-
220V 15kW Skid-Mounted Evaporator With Automatic Feed System and IP65 EnclosureUS$ 32600 - 875000MOQ: 1 Combo
-
Skid-Mounted Evaporator With Free Installation Training and 24-Month Warranty for Overseas ClientsUS$ 32600 - 875000MOQ: 1 Combo
-
≥0.5t/H Skid-mounted Forced Circulation Double-effect MVR Crystallization EvaporatorUS$ 830 - 738000MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our 304 Stainless Steel Skid-Mounted Evaporator with PLC Control – a robust, efficient solution tailored for industrial wastewater treatment. With over 8 years of manufacturing experience and a dedicated R&D team, we have engineered this evaporator to deliver consistent performance, energy savings, and easy integration into existing treatment lines. Our factory, spanning 10,000–30,000 square meters, ensures strict quality control and on-time delivery.
This evaporator is designed for demanding environments where corrosion resistance and reliability are paramount. The 304 stainless steel construction guarantees long service life, while the Programmable Logic Controller (PLC) automates the entire evaporation process, reducing manual intervention and human error. Whether you treat oily wastewater, landfill leachate, or chemical effluents, this skid-mounted unit can be customized to meet your specific volume and concentration needs.
Key Features & Technical Specifications
- Material: 304 stainless steel for all wetted parts – resistant to corrosion, easy to clean, and compliant with food-grade & industrial standards.
- PLC Control: Automatic monitoring of temperature, pressure, flow rate, and liquid level; real-time data display and remote communication optional.
- Skid-Mounted Design: Compact footprint, pre-piped, and pre-wired – reduces installation time and cost; forklift or crane movable.
- Energy Efficiency: Mechanical vapor recompression (MVR) or thermal vapor recompression (TVR) options available to minimize energy consumption.
- Capacity: Configurable from 200 L/h to 10,000 L/h, with multi-effect configurations for higher throughput.
- Safety: Integrated alarms for over-temperature, over-pressure, and low water level; emergency shut-off system.
- Operation: Touchscreen HMI with multilingual interface; password-protected settings; automatic start/stop routine.
| Parameter | Value |
| Material Grade | 304 Stainless Steel (SS304) |
| Control System | PLC + Touch Screen HMI (Siemens/Delta optional) |
| Evaporation Type | Falling Film / Forced Circulation / MVR (upon request) |
| Design Temperature | Up to 120°C (adjustable) |
| Operating Pressure | Atmospheric or vacuum (customizable) |
| Power Supply | 380V/50Hz, 3-phase (other voltages available) |
| Dimensions (L x W x H) | Varies by capacity; standard skid size approx. 3m x 2m x 2.5m |
Advantages for Your Business
- Cost Savings: Reduce wastewater disposal fees by up to 90% through on-site volume reduction. Lower energy consumption via efficient heat recovery.
- Compliance Ready: Meet stringent environmental regulations with a reliable treatment process. Effluent quality can satisfy discharge or reuse standards.
- Minimal Downtime: PLC diagnostics alert operators to potential issues before they cause shutdowns. Spare parts support from Qingdao warehouse.
- Easy Expansion: Modular design allows multiple units to be combined for higher capacity. Skid-mounted nature simplifies future relocation.
- User-Friendly: Automated cleaning cycles (CIP) reduce manual labor. Remote monitoring via Ethernet/IP or 4G optional.
At Qingdao Conqinphi Environmental Technology Group, we have successfully delivered over 300 industrial wastewater treatment systems to clients across North America, South America, Europe, Asia, and Africa. Our annual export value exceeds US$10 million, a testament to the trust global customers place in our products. With ISO9001, ISO14000, OHSAS18001, and multiple other certifications (including HACCP, SA8000, etc.), we adhere to the highest quality and safety standards.
Our factory employs 201–300 skilled workers and engineers, capable of producing custom configurations within short lead times. We offer comprehensive after-sales support, including installation guidance, remote troubleshooting, and spare parts supply. When you choose our 304 Stainless Steel Skid-Mounted Evaporator, you're investing in a durable, high-performance machine backed by a company with a proven track record.
Contact us today for a tailored quotation or technical consultation. Let us help you turn your wastewater treatment challenge into a sustainable, cost-effective solution.
Frequently Asked Questions (FAQ)
-
What types of wastewater can this evaporator handle?
It is suitable for industrial wastewater with high salinity, oil emulsion, chemical effluents, landfill leachate, and many other water-based wastes. For specific chemicals, please contact our engineers for material compatibility review. -
Is the PLC control system easy to operate for non-technical staff?
Yes, the touchscreen interface provides intuitive menu navigation and pre-set programs. Training manuals and on-site support are available. -
What is the typical energy consumption per liter of water evaporated?
Energy consumption depends on the evaporation technology chosen. For our MVR system, it can be as low as 20–30 kWh per ton of water evaporated (theoretical). Please request a detailed energy analysis for your specific feed water. -
Can the skid-mounted evaporator be installed outdoors?
Yes, the unit is designed with weather-resistant enclosures (IP55 minimum). However, we recommend a sheltered area for extreme climates. Optional insulation and heating for cold environments are available. -
What maintenance is required?
Routine checks include cleaning of heat exchange surfaces, inspection of seals and gaskets, and calibration of sensors. The PLC logs operational data to help schedule preventive maintenance. -
Do you provide certifications like CE or ASME?
Our products are manufactured according to ISO standards and we can provide documents such as material certificates and pressure test reports. Specific certification (e.g., CE, ASME) can be arranged upon request with additional lead time and cost. -
What is the warranty period and after-sales support?
Standard warranty is 12 months. Extended warranty options are available. We offer 24/7 remote support and a network of service partners in major markets. -
How long does it take to manufacture and ship to my port?
Lead time depends on the configuration – typically 30–45 days for standard models. We ship from Qingdao Port, China, and can arrange express delivery for urgent orders.
