Help CenterSkid-mounted Evaporator 220V 50Hz With Automatic Feed Pump, 304 SS, Evaporation Area 10m², CE Compliant
Product Spotlights
Related Products
-
Skid-mounted Evaporator 304 Stainless Steel PLC Control 220V Automatic Evaporating Capacity 500L/HUS$ 2700 - 855000MOQ: 1 Combo -
Industrial Skid-mounted Evaporator PLC Touch Screen, 200L/H Capacity, 304 Stainless Steel, IP54 EnclosureUS$ 2700 - 855000MOQ: 1 Combo
-
Skid-mounted Evaporator for Wastewater Treatment, 380V, 1000L/H, 316L Stainless Steel, Automatic OperationUS$ 2700 - 855000MOQ: 1 Combo
-
Skid-mounted Evaporator 380V 60Hz, 1500L/H, 316 Stainless Steel, Heat Exchanger Type, Automatic DrainageUS$ 2700 - 855000MOQ: 1 Combo
-
Compact Skid-mounted Evaporator With 316L Stainless Steel, Temperature Control, 380V 3-Phase, 1000L/HUS$ 2700 - 855000MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015, is a professional manufacturer of skid-mounted evaporators with a factory spanning 10,000–30,000 square meters. Our Skid-mounted Evaporator 220V 50Hz with Automatic Feed Pump, 304 SS, Evaporation Area 10m², CE Compliant is designed to deliver reliable, efficient evaporation for industrial wastewater and process liquids. With an annual export value of US$10–50 million and a team of 201–300 employees, we bring years of expertise and global supply chain capability to every unit. This evaporator combines corrosion-resistant 304 stainless steel construction with a compact, skid-mounted design for easy installation and maintenance, making it a versatile solution for various industries.
Key Features & Specifications
- High-Performance Evaporation: 10 m² evaporation area ensures efficient liquid concentration, reducing waste volume by up to 90%.
- Automatic Feed Pump: Integrated pump automatically adjusts feed rate based on liquid level, minimizing manual intervention.
- 304 Stainless Steel Construction: All wetted parts made of 304 SS for excellent corrosion resistance against acids, alkalis, and saline solutions.
- 220V 50Hz Power Supply: Standard single-phase power suitable for most industrial and commercial facilities, with optional voltage configurations available upon request.
- Skid-mounted Design: Pre-assembled on a sturdy steel frame, ready for quick installation – just connect utilities and start operation.
- CE Compliant: Designed and manufactured in accordance with CE standards, ensuring safety and quality for European and global markets.
- Compact Footprint: Space-saving layout allows installation in tight spaces, ideal for retrofit projects.
- Low Maintenance: Simple construction with easy access to heating elements and pump for cleaning and servicing.
Technical Specifications
| Parameter | Value |
|---|---|
| Evaporation Area | 10 m² |
| Power Supply | 220V / 50Hz / 1-phase |
| Material | 304 Stainless Steel |
| Feed Pump Type | Automatic, centrifugal |
| Dimensions (L×W×H) | Customizable – standard: 2000×1200×1800 mm |
| Weight | Approx. 350 kg |
| Operating Temperature | Up to 100°C (depending on liquid) |
| Compliance | CE |
Customer Benefits
- Reduce Operational Costs: By concentrating waste liquids, you lower disposal costs and recover valuable water or chemicals.
- Easy Integration: The skid-mounted unit arrives fully assembled, reducing installation time and labor costs.
- Automatic Operation: The automatic feed pump adjusts flow based on real-time conditions, ensuring consistent performance without constant monitoring.
- Long Service Life: 304 SS resists corrosion and scaling, extending equipment lifespan even in harsh environments.
- Global Compatibility: 220V 50Hz power is standard in many regions; CE compliance facilitates export to Europe and other markets.
- Customizable Options: Additional features like PLC control, remote monitoring, or different voltage configurations are available upon request.
Why Choose Qingdao Conqinphi?
As a manufacturer with over 9 years of experience, we have supplied skid-mounted evaporators to clients across North America, South America, Europe, Asia, and Africa. Our factory is ISO9001 certified (among other certifications like HACCP, OHSAS18001, etc.), ensuring rigorous quality control from raw material sourcing to final assembly. With an annual export value exceeding US$10 million, we have a proven track record of delivering reliable equipment on time. Every unit undergoes functional testing before shipment, and we provide comprehensive after-sales support including technical documentation, spare parts, and remote troubleshooting.
Contact us today to discuss your specific evaporation needs. Our team can provide detailed engineering drawings, performance data, and a customized proposal based on your liquid composition and required throughput. Experience the difference of a professional, ISO-certified manufacturer committed to your success.
Frequently Asked Questions
Q1: What is the maximum evaporation rate of this skid-mounted evaporator?
A: The evaporation rate depends on the liquid properties (e.g., boiling point, viscosity) and operating temperature. Typically, with a 10 m² area and water-like liquids, you can achieve approximately 50–100 liters per hour. Contact us for a detailed calculation based on your specific fluid.
Q2: Can this evaporator handle corrosive liquids like strong acids?
A: The 304 stainless steel construction provides good resistance to many organic acids, mild alkalis, and saline solutions. For highly corrosive media (e.g., concentrated hydrochloric acid), we recommend upgrading to 316L or other alloys. Please provide your liquid composition for a material compatibility assessment.
Q3: Does the automatic feed pump work with high-viscosity liquids?
A: The standard centrifugal pump is designed for low to medium viscosity (up to about 200 cP). For higher viscosities, we can offer an optional gear pump or progressive cavity pump. Customization is available upon request.
Q4: What is the power consumption of the unit?
A: The total power consumption depends on the heating method (electric or steam). For electric heating, typical power rating is around 6–12 kW for this size. The feed pump draws about 0.5–1 kW. Exact figures are provided in the technical datasheet.
Q5: Is the skid-mounted evaporator easy to install?
A: Yes. The unit comes pre-assembled on a skid with all piping, valves, and controls mounted. You only need to connect the power supply, feed inlet, concentrate outlet, and condensate drain. Installation can be completed within a few hours by a qualified technician.
Q6: How do you ensure quality and reliability?
A: Our factory is ISO9001 certified, and each evaporator undergoes a 100% functional test before shipment. We use high-quality 304 stainless steel from reputable mills, and all welds are inspected. We also provide a one-year warranty against manufacturing defects.
Q7: Can I get a unit with different voltage or frequency?
A: Yes. While the standard model is 220V 50Hz, we can customize the electrical components for 380V, 415V, 60Hz, or other specifications. Please inquire with your requirements.
Q8: What is the delivery time and shipping port?
A: Standard delivery time is 25–35 working days after order confirmation. We ship from Qingdao Port, China, with flexible packaging options (export wooden case or container).
