Help CenterStainless Steel MVR Evaporation Crystallization System With Mechanical Vapor Compressor, PLC Controlled, 800L/h
Product Spotlights
Related Products
-
Pharmaceutical Grade MVR Evaporation Crystallization System, 316L SS, Used for API Crystallization ProcessUS$ 6840 - 748000MOQ: 2 Combos -
Reliable MVR Evaporation Crystallization System, Mill Test Report Provided, Standard Compliant Design, After-Sales ServiceUS$ 6840 - 748000MOQ: 2 Combos
-
Compact MVR Evaporation Crystallization System, 500L/h Rate, Three-Phase 380V, 316L SS, Low Energy ConsumptionUS$ 6840 - 748000MOQ: 2 Combos
-
MVR Evaporation Crystallization System With 1-Year Warranty, Free Technical Training, On-site Installation SupportUS$ 6840 - 748000MOQ: 2 Combos
-
Energy-Saving MVR Evaporation Crystallization System, 304 Stainless Steel, Automatic Operation, 220V/50HzUS$ 6840 - 748000MOQ: 2 Combos
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd., a leading manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and an annual export value between US$10 million and US$50 million. Our Stainless Steel MVR Evaporation Crystallization System with Mechanical Vapor Compressor, PLC Controlled, 800L/h is engineered to deliver high-efficiency evaporation and crystallization for industries ranging from chemical processing to wastewater treatment. By integrating advanced mechanical vapor recompression (MVR) technology and precise PLC automation, this system significantly reduces energy consumption while ensuring stable, continuous operation.
The core of this system lies in its ability to reuse vapor latent heat through compression, achieving up to 70–90% energy savings compared to traditional evaporators. Crafted from durable stainless steel, it resists corrosion and maintains product purity, making it ideal for sensitive solutions. The 800L/h capacity is designed for medium-scale production, offering flexibility for both standalone use and integration into larger processes.
Below we detail the key features, technical specifications, and operational advantages of this robust equipment.
Key Features & Technical Specifications
- Energy Efficient MVR Technology: Mechanical vapor compressor recycles latent heat; typical energy consumption is only 20–50 kWh per ton of water evaporated, depending on solution characteristics.
- PLC Controlled Automation: Siemens or equivalent PLC with HMI touchscreen for real-time monitoring of temperature, pressure, flow rate, and level. Remote control and data logging options available.
- Stainless Steel Construction: Entire system made from SS304 or SS316L (customizable), ensuring excellent corrosion resistance and longevity.
- Compact Modular Design: Pre-assembled skid-mounted structure reduces on-site installation time and footprint.
- Multiple Configuration Options: Can be designed for falling film, forced circulation, or scraped film evaporation to suit different feed viscosities and fouling tendencies.
- Safety & Compliance: Equipped with overpressure protection, emergency shutdown, and automatic fault diagnosis. System operates under vacuum to lower boiling temperature and reduce scaling.
- Adaptable to Various Industries: Suitable for brine concentration, zero liquid discharge (ZLD), chemical crystallization, pharmaceutical intermediates, food extracts, and more.
| Parameter | Specification |
|---|---|
| Evaporation Capacity | 800 L/h (water evaporation, adjustable) |
| Operating Temperature | 40–100°C (control via PLC) |
| Vapor Compressor Type | Centrifugal or Roots blower (customizable) |
| Power Supply | 380V/50Hz or other voltages upon request |
| Control System | PLC + HMI (Siemens/Mitsubishi optional) |
| Material | Stainless Steel (SS304, SS316L, or dual-phase) |
| Dimensions (L×W×H) | Customized (approx. 4000×2000×3500 mm for standard) |
| Weight | Approx. 4–6 tons (varies with configuration) |
| Certifications | ISO9001, ISO14000, OHSAS18001 (factory certified) |
Why Choose Our MVR Evaporation Crystallization System?
- Proven Energy Savings: Recover up to 95% of latent heat, drastically lowering operating costs. Typical payback period is less than 2 years.
- Intelligent PLC Control: Automatic start/stop, adaptive PID regulation, and alarm history. Operators require minimal training.
- High Quality Construction: All wetted parts are stainless steel with smooth surfaces to prevent fouling and ease cleaning.
- Versatile Process Application: Handles both evaporation and crystallization in one unit. Crystal size can be controlled by adjusting supersaturation and residence time.
- Reliable After-Sales Support: Qingdao port delivery, 24/7 technical hotline, and optional on-site commissioning services.
Company Trust & Global Reach
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been serving global markets since 2015. With a factory size of 10,000–30,000 m² and over 200 skilled employees, we have exported to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our annual export value exceeds US$10 million, reflecting the trust and satisfaction of international clients. We hold multiple quality management certifications including ISO9001, ISO14000, OHSAS18001, and others, which ensure that every system is manufactured under strict quality control.
Our MVR Evaporation Crystallization System is designed to help you achieve sustainable production with lower energy consumption and higher efficiency. Whether you need to concentrate brine, recover valuable chemicals, or achieve zero liquid discharge, this system offers a reliable solution. We invite you to contact us for a customized proposal and technical consultation.
Frequently Asked Questions (FAQ)
Q1: What types of feed solutions can this MVR system handle?
A: It is suitable for aqueous solutions with low to medium viscosity, such as brine, chemical process streams, pharmaceutical intermediates, and food extracts. For highly viscous or scaling-prone liquids, we can modify the circulation type (forced circulation or scraped film).
Q2: How much energy does the MVR compressor consume?
A: Typically, the compressor consumes between 20–50 kWh per ton of water evaporated, depending on the boiling point elevation and required compression ratio. This is 5–10 times less than traditional multi-effect evaporators.
Q3: Can the PLC system integrate with existing plant DCS or SCADA?
A: Yes, the PLC supports common communication protocols such as Modbus, Profibus, or Ethernet IP. Integration can be customized upon request.
Q4: What is the minimum order quantity (MOQ) and delivery time?
A: MOQ is 1 set. Standard delivery time is 45–60 days after down payment, depending on customization complexity.
Q5: Do you provide on-site installation and commissioning?
A: Yes, we offer optional on-site technical support including installation supervision, commissioning, and operator training. Quotation can be provided separately.
Q6: How do you handle scaling or fouling in the evaporator?
A: We design the system with anti-scaling features such as low-temperature operation (under vacuum), proper flow velocity, and optional CIP (clean-in-place) nozzles. For severe scaling, a forced circulation design is recommended.
Q7: What spare parts should be kept in stock?
A: We recommend keeping spare gaskets, seals, and a set of sensors (temperature, pressure, level). A complete spare parts list is provided with the system manual.
Q8: Is the system compliant with international standards for export?
A: Yes, all our systems are manufactured under ISO9001 certified processes. Electrical components comply with IEC standards, and pressure vessels can be designed to ASME, PED, or GB standards as required.
For more details or to discuss your specific application, please reach out to our sales team. We are committed to providing a high-quality, energy-efficient evaporation crystallization solution tailored to your process.
