log washer quotation request
1. Product Introduction
The Log Washer is a specialized, high-efficiency washing equipment designed to scrub, cleanse, and separate tough, plastic clays, cemented aggregates, and heavy contaminants from ores and construction stone. Named after its historical predecessor that used wooden logs with metal blades, modern log washers feature dual counter-rotating steel shafts fitted with high-strength, wear-resistant alloy paddles. It is the definitive industry choice when standard screw washers or rotary screens cannot break down sticky clay-bound materials.
2. Applications
Log washers are widely deployed in mining, quarrying, and aggregate processing where raw materials are heavily contaminated with plastic mud or tough clay.
Mining & Ores: Processing of iron ore, manganese, bauxite, copper, gold, and limestone before smelting or leaching.
Construction Aggregates: Cleaning crushed stone, gravel, and coarse sand to meet strict infrastructure and concrete quality standards.
Recycling & Remediation: Washing demolition waste, contaminated soil, and glass cullet to separate recyclable minerals from sticky dirt.
3. Working Principle
The log washer utilizes an inclined tank (typically angled at 6° to 12°) and the mechanical force of interlocking paddles to achieve rigorous scrubbing.
Difference Between Spiral Sand Washing Machine And Log WasherDifference Bet…
1.Feeding & Slurrying: Raw material enters from the lower end of the inclined washing trough, while water is introduced from the bottom or spray bars above.
2.Material-on-Material Attrition: The dual shafts rotate counter-directionally toward each other. The alternating paddles aggressively cut, punch, and tumble the feed material. This creates severe friction, forcing the rocks to grind against each other (material-on-material attrition), which strips away stubborn, cemented clay coatings.
3.Counter-Current Washing: Clean, heavier aggregates are conveyed up the incline by the pitch of the paddles and are discharged at the top end (Ore discharge). Meanwhile, the dissolved mud and lighter waste combine with water to form a slurry, flowing in the opposite direction to discharge via the weir at the lower end (Clayey overflow).
4. Key Advantages
Ultimate Scrubbing Power: Unlike standard sand washers, log washers handle extremely sticky plastic clays (e.g., "soluble clays") by cutting and breaking them up mechanically rather than just rinsing them.
High Wear Resistance: Equipped with replaceable, bolt-on paddles made from high-chromium or manganese alloy steel, drastically minimizing downtime and maintenance costs.
Extended Retention Time: The long tub design and adjustable slope ensure materials remain under intense scrubbing action long enough to ensure absolute cleanliness.
Heavy-Duty Drive System: Utilizes massive, high-torque gearboxes and robust electric motors capable of starting under full load conditions.
Higher Yields: Maximizes the recovery of valuable minerals and clean stone that would otherwise be rejected as waste due to mud contamination.
5. Case Studies and Images
