Popular Model BK5032 Metal CNC 3/4 Axis Slotting Machine With High Precision
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Popular Model B5020 Factory Sale Price Cheap Keyway Slotting MachineNegotiableMOQ: 1 -
Price of Vertical Shaper Machine B5032 for Metal Vertical Slotting MachineNegotiableMOQ: 1
-
Model BK5018 Good Price CNC Slotting MachineNegotiableMOQ: 1
-
BK5018 Heavy Duty Cnc Vertical Slotting Machine With High PrecisionNegotiableMOQ: 1
-
Factory Direct Sell Vertical Metal Slotting Machine BC5050 With CE StandardNegotiableMOQ: 1
Products Description
INTRODUCTION:
1. The working table of the machine tool is provided with three different directions of feed (longitudinal, horizontal and rotary), therefore work object go through once clamping, Several surfaces in the machine tool machining,
2. Hydraulic transmission mechanism with sliding pillow reciprocating motion and hydraulic feed device for working table.
3. The sliding pillow has the same speed in every stroke, and the movement speed of the ram and the working table can be adjusted continuously.
4. Hydraulic control table have ram commutation oil for oil reversing mechanism, In addition to hydraulic and manual feed outer,Even there single motor drive vertical, horizontal and rotary fast moving.
5. Use hydraulic feed the slotting machine, Is when the work is over turning back instantaneous feed, Therefore be better than mechanical slotting machine used drum wheel feed.
Application:
This machine be used for interpolation plane, forming surface and Keyway Etc. And can insert the inclination in the 10° Mold and other within the scope of etc. work matter,Enterprise suitable for single or small batch production.
Specification |
unit |
BK5030 |
BK5032 |
Max length of ram |
mm |
300 |
320 |
Ram adjustment stroke |
mm |
75 |
315 |
Number of ram movements |
N/min |
30-180 |
20/32/50/80 |
Worktable size |
mm |
550x405 |
600x320 |
Table travel X/Y |
mm |
280x330 |
620x560 |
The distance between the axis of the tool bearing hole and the forearm of the column |
mm |
505 |
600 |
The distance between the end face of the cutter head support hole and the table |
mm |
540 |
590 |
X direction motor torque |
(N.M.) |
6 |
7.7 |
Y direction motor torque |
(N.M.) |
6 |
7.7 |
Fast moving |
X(m/min) |
5 |
5 |
Y(m/min) |
5 |
5 |
|
Ball screw(X) |
FFZD3205-3/P4 |
FFZD3205-3/P4 |
|
Ball screw(Y) |
FFZD3205-3/P4 |
FFZD3205-3/P4 |
|
Main motor power |
kw |
3.7 |
4 |
Machine weight (approx.) Kg |
kg |
3500 |
3700 |
Packing size |
mm |
2600/2300/2450 |
2800/2400/2550 |
Details Images
Application
Package&Delivery
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the
European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the
European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
